Powersoft Quattrocanali 4-Channel Amplifier Class D Install Platform | 2404 | DSP+
Powersoft Quattrocanali 4-Channel Amplifier Class D Install Platform | 2404 | DSP+
SoundPro Item: 133416 | Part Number: Quattrocanali 2404 DSP+
Usually ships in 5-7 business days
- 4-Channel Class D Platform Supports Lo-Z And 70V/100V Distributed Lines Simultaneously
- Patented SRM Technology Recycles Reactive Energy To Reduce Power Consumption And Heat
- 1U Rack Form Factor Keeps Multi-Amp Installs Compact
- Available Across Four Power Output Tiers To Right-Size Any Installation
- DSP, DSP+, And DSP+D Versions Offer Scalable Control And Monitoring Options
- DSP+D Variant Enables System And Load Monitoring Via ArmoníaPlus Software
The Quattrocanali series is a 4-channel, Class D power amplification platform engineered for small- to medium-scale installed sound environments where operational flexibility and reliable audio performance are non-negotiable. AV integrators working in corporate spaces, houses of worship, hospitality venues, and educational facilities will find the series capable of driving Lo-Z speaker loads, 70V distributed lines, 100V distributed lines, or any combination of the three from a single rack unit. That mixed-load capability removes the need for separate amplifier platforms across zones with different wiring topologies, simplifying system design and reducing rack space.
Every model in the series incorporates Powersoft's patented SRM (Smart Rail Management) technology, which captures reactive energy returning from loudspeakers and recycles it back into the power supply rail. The practical result for an installed system is lower steady-state power draw, reduced heat output, and lower long-term operating costs compared to conventional Class D designs. The 1U form factor keeps rack layouts compact even when multiple amplifiers are required across a larger distributed system.
The Quattrocanali range is available across four power output tiers and three DSP versions, including a DSP+D variant that adds comprehensive amplifier control and system load monitoring via PC and the ArmoníaPlus software platform. That breadth of configuration options lets integrators right-size both the power and the control architecture for each project without switching amplifier families.
Downloads
Downloads
- Application Note AES67 configuration on DSP+ and A+ models
- Application Note Amplifiers Backup strategy and Startup times
- Application Note Damping Control
- Application Note HealthPlus
- Application Note Integrating Powersoft amplifiers in a Dolby Atmos system
- Application Note Limiters basic concept and operations
- Application Note Line Integrity Monitoring and Pilot Tones
- Application Note Power Sharing
- Application Note Powersoft Amplifiers and AoIP (Dante AES67)
- Application Note VCA Operation and remote Off GPI
- Application Note Web App for Powersoft Amplifiers
- CB Certificate NL 102706
- CCC Certificate 2017010802984031
- CE Verification of Conformity AT EMC 838 0522A
- CE Verification of Conformity AT LVD 838 0222A
- CSA Certificate 80023853
- Declaration of Conformity DoC Powersoft Quattrocanali Series
- Duecanali + Quattrocanali User Guide Multilingual
- EPA Declaration of Conformity Powersoft
- FCC Supplier's Declaration of Conformity SDoC Powersoft Quattrocanali Series
- Quattrocanali Datasheet
- Quattrocanali DSP+ Series Datasheet
- Quattrocanali DSP+D Series Datasheet
- Quattrocanali DSP Series Datasheet
- REACH Declaration of Conformity
- RoHsCE Declaration of Conformity Powersoft
- RoHsChina Declaration of Conformity
- UK Declaration of Conformity DoC Powersoft Quattrocanali Series
