Powersoft Quattrocanali 4-Channel Amplifier Class D Install Platform | 2404 | DSP+D

Powersoft Quattrocanali 4-Channel Amplifier Class D Install Platform | 2404 | DSP+D

SoundPro Item: 58433 | Part Number: Quattrocanali 2404 DSP+D

$4,288.00
$4,288.00 $4,288.00
Your Price Sold out
MSRP: $4,288.00 | MAP: $4,288.00

Usually ships in 5-7 business days

  • 4-Channel Class D Platform Supports Lo-Z And 70V/100V Distributed Lines Simultaneously
  • Patented SRM Technology Recycles Reactive Energy To Reduce Power Consumption And Heat
  • 1U Rack Form Factor Keeps Multi-Amp Installs Compact
  • Available Across Four Power Output Tiers To Right-Size Any Installation
  • DSP, DSP+, And DSP+D Versions Offer Scalable Control And Monitoring Options
  • DSP+D Variant Enables System And Load Monitoring Via ArmoníaPlus Software
Log in or register for YOUR best price

The Quattrocanali series is a 4-channel, Class D power amplification platform engineered for small- to medium-scale installed sound environments where operational flexibility and reliable audio performance are non-negotiable. AV integrators working in corporate spaces, houses of worship, hospitality venues, and educational facilities will find the series capable of driving Lo-Z speaker loads, 70V distributed lines, 100V distributed lines, or any combination of the three from a single rack unit. That mixed-load capability removes the need for separate amplifier platforms across zones with different wiring topologies, simplifying system design and reducing rack space.

Every model in the series incorporates Powersoft's patented SRM (Smart Rail Management) technology, which captures reactive energy returning from loudspeakers and recycles it back into the power supply rail. The practical result for an installed system is lower steady-state power draw, reduced heat output, and lower long-term operating costs compared to conventional Class D designs. The 1U form factor keeps rack layouts compact even when multiple amplifiers are required across a larger distributed system.

The Quattrocanali range is available across four power output tiers and three DSP versions, including a DSP+D variant that adds comprehensive amplifier control and system load monitoring via PC and the ArmoníaPlus software platform. That breadth of configuration options lets integrators right-size both the power and the control architecture for each project without switching amplifier families.

Downloads

View full details

Specifications

Performance
Key Power Spec
800W@2Ω / 1200W@100V
Channels
4 ch
Dimensions
Width
19.0"
Depth
14.1"
Height
1.75"
Width (mm)
483 mm
Depth (mm)
358 mm
Height (mm)
44.5 mm
Weight
Product Weight
15.4 lbs (7 kg)
Construction
Form Factor
1U
