Specifications
Auxiliary Input
1/8 in (3.5 mm) Stereo
Connectivity
Bluetooth: V5.0
Inputs
Four - (2 x XLR/TRS Mic/Line Combo, 1 x 1/8” TRS Stereo, Bluetooth Stereo)
Line Out
One - 1 x XLR Mix Out
Power Consumption
3.3A (230V-50 Hz), 6.6A (120V)
VoltageRequirements
100-240 VAC, 50-60 Hz
Amplifier Type
Class-D
Audio Controls
Gain, Volume, Hi/Lo EQ
Cabinet Material
H-PP Molded
Cooling
Passive radiator
Grille Material
1.2 mm Steel
HF Powere
468W
HF Transducers
1” Compression
Handle
1 Top
LF Power
1060W
LF Transducers
10"(2.36” Voice Coil)
Pole Socket
Dual Position (0˚, 7.5˚)
Line Input Connection Type
XLR/TRS Mic/Line Combo
Line Inputs Impedance
30K ohm
Line Inputs Maximum Level
+14dBu
Microphone Preamp Input Impedance
30K ohm
Dimensons (D x H x W)
11.5" (29.1 cm) x 20.3" (51.6 cm) x 11.8" (30.0 cm)
Product Weight
30.9 lbs (13.9 kg)
DSP Features
Speaker modes, Location, Bass, Treble
Power Cable
IEC
Protections
Output limiter
Suspension
M10 Suspension Points, Flypoints: 2 Top, 1 Back
Line Outputs Connection Type
XLR Male, Balanced
Peak SPL
130dB
Total Power Output
1500Watts
Coverage Pattern
90 degree (H) x 60 degree (V)
Crossover Frequency
2.2 kHz
Speaker Type
Active 2-Way
