Specifications
Connectivity
Bluetooth: V5.0
Channels
Two
Inputs
Three - 2 x XLR/TRS Line Combo, Bluetooth
Line Out
Two - 2 x XLR Link Out
Power Consumption
5.6A (230V-50 Hz), 11.1A (120V)
VoltageRequirements
100-240 VAC, 50-60 Hz
Amplifier Type
Class-D
Audio Controls
Gain, Volume, Hi/Lo EQ, X-over
Cabinet Material
15mm Plywood
Cooling
Passive radiator
Grille Material
1.5 mm Steel
Handle
2 Side
LF Transducers
15” (3” Voice Coil)
Pole Socket
Ground-Stack Provisions
Line Input Connection Type
XLR/TRS Mic/Line Combo
Line Inputs Impedance
14K ohm
Line Inputs Maximum Level
+25dBu
Dimensions (D x H x W)
25.8" (65.6 cm) x 26" (66.0 cm) x 19.3" (49.0 cm)
Product Weight
88.4 lbs. (39.8 kg)
DSP Features
Low-pass EQ, crossover, delay, polarity and “Mo’Bass” mode
Power Cable
IEC
Protections
Output limiter
Line Outputs Connection Type
XLR Male, Balanced
Peak SPL
130 dB
Total Power Output
2000 Watts
Crossover Frequency
60 Hz - 150 Hz
Speaker Type
Active Vented Design
