Specifications
Dimensions
Dimensions (H X W X D)
18.5 x 20.5 x 18.25 inches (470 x 521 x 464 mm)
Weight
Unit Weight
63 lbs. (28.6 kg)
Electrical
Line Input Impedance
40 kΩ
AC Power Consumption (1/8 Power)
4.2 Amps
Audio
Maximum Peak SPL
130 dB
Crossover Frequency
420 Hz
Performance
Bandwidth
20 Hz - 20 kHz
Connectivity
Total Power Output
2000W Peak, 1000W Program (500W RMS)
Input Channels
1 Line
Input Connector Types
1 XLR
Maximum Input
+4 dBu
Output Connector
Direct Line Out (XLR)
AC Power Input
90-260V~, 50-60 Hz
Construction
Material
15mm Polypropylene
Grille
Powder-coated steel
Mounting
Dual-position pole mount (0° and 7.5°) 35 mm
General
Frequency Response (-3 dB)
48 Hz – 18 kHz
Nominal Coverage (-6 dB)
120° (H) x 15° (V) per enclosure
LF Transducer
12” (2.5” voice coil)
HF Transducer
8 x 2” (1” Voice Coil)
Type
Class D
LF Power
1000W Peak, 500W Program (250W RMS)
HF Power
1000W Peak, 500W Program (250W RMS)
Dynamic Range
119 dB (A-weighted)
Mains Connection
Locking AC In and Out
Rigging Points
Integrated Rigging (10:1 load)
Cable
Configuration
Active 2-way
