Specifications
Dimensions
Dimensions (HxDxW)
1.25x2.88x5.25"
Electrical
Headphone Impedance Working Range
>12Ω
Battery Power
9V
Audio
Input Impedance
15kΩ
Max Output Power
50mW/channel, <0.01% THD+N, 20Ω load
Frequency Response
30Hz - 20kHz, +/-2dB
Connectivity
Connector Type
XLR female
Max Input Level
+4 dBV <0.01% THD+N, unity gain
Limit Input Level
+5dBm
Shipping
Weight
1 pound (0.45 kg)
General
External Adapter Type
9VDC, 40mA, center pin negative
