Specifications
Dimensions
Dimensions (HxDxW)
1.75" x 5.5" x 5.5"
Electrical
THD+N
0.0025%, 1 kHz, unity gain
Headphone Impedance Working Range
32Ω - 600Ω
Audio
Input Impedance
10kΩ
Frequency Response
20Hz - 20kHz (+/-0.5dB)
Output Impedance
51Ω
Max Output Power
130mW/Ch. <0.5% THD+N, 60Ω load
Connectivity
Connector Type
1/4" TRS balanced
Max Input Level
+18 dBu, <0.5% THD+N, unity gain
Max Output Level
+18 dBu, <0.5% THD+N
Shipping
Weight
5 pounds (2.27 kg)
General
External Adapter Type
+12 VDC, 1000 mA, center pin positive
