Specifications
Dimensions
Bit Depth
24-bit
Dimensions (HxWxD)
3.5x11x12.3"
Electrical
THD+N
< 0.01% (min. gain, A-wtd)
Input Voltage Range
90 to 240 VAC
Audio
Gain Control Range
43dB (12 to 55dB)
Frequency Response to Analog Outputs
20Hz to 20kHz, +0.5/-1.5 dB
Frequency Response to USB (direct)
20Hz to 20kHz, +0.5/-1.5 dB
Input Impedance
1 kΩ
Phantom Power
+48V, +/-3V, global
Frequency Response
20Hz to 20kHz, +0.5/-1.5dB
ADC Dynamic Range
114dB (component), 105dB (measured, A-wtd, 48kHz)
DAC Dynamic Range
114dB (component), 105dB (measured, A-wtd, 48kHz)
Signal-to-noise
-96dB (A-weighted)
Connectivity
Max Input Level
+9 dBu +/-1.0 dB (unity gain)
S/N Ratio to Outputs
94dB (+4 dBu)
S/N Ratio to Analog Outputs
85dB (+4dBu)
Max Output Level
150 mW/channel @ 60 Ω
Input to Output
-90 dBu (ref = +4dBu, 20 Hz to 20 kHz, unwtd)
Power Connector
IEC
Shipping
Weight
7.1 pounds (3.2 kg)
General
Type
XLR female, Class A XMAX
Common Mode Rejection Ratio
65dB (1kHz, +55dB gain)
Dynamic Range
>105dB (min. gain, A-wtd), >108dB (mid. gain, unwtd)
Adjacent Channels
-85 dBu (ref = +4 dBu, 20 Hz to 20 kHz, unwtd)
Internally Supported Sample Rates
44.1, 48, 88.2, 96 kHz
Jitter
< 80 ps RMS (20 Hz – 20 kHz)
Jitter Attenuation
> 60 dB (1 ns in => 1 ps out)
Supported Media Format
FAT16 formatted SD™ card, FAT32 formatted SDHC™ card
Media Storage Capacity
SD card 2 GB; SDHC card 32 GB
Recording File Format
Stereo WAV
Playback File Formats
Stereo WAV, MP3 (96-320 kbs, 32 / 44.1 / 48 kHz)
Sampling Rate (WAV)
44.1kHz
