Specifications
Performance
Nominal Capacitance, Conductor to Conductor
80 pF/m / 24.4 pF/ft
Nominal Capacitance, Conductor to Shield
185 pF/m / 56.4 pF/ft
Nominal Inductance, Conductor to Conductor
0.7 µH/m / 0.213 µH/ft
Nominal Inductance, Conductor to Shield
0.2 µH/m / 0.061 µH/ft
Nominal DC Resistance per Conductor
40 Ω/km / 12.2 Ω/1,000 ft
Nominal DC Resistance of Shield
20 Ω/km / 6.1 Ω/1,000 ft
Nominal Characteristic Impedance
93.5 Ω
Insulation Resistance, Conductor to Shield
Greater than 1 GΩ
Weight
Product Weight
3.00 lbs
Shipping Weight
0.40 lbs
Shipping
Box Dimensions
1.00" x 3.00" x 8.00"
Shipping Method
Parcel
Identifiers
UPC
022099558958
