Specifications
Construction
Conductor
20 AWG x 2 Oxygen-Free Copper (OFC)
Shield
93% Braided OFC
Signal Type
Balanced
Electrical
Nominal Capacitance, Conductor to Conductor
24.4 pF/ft (80 pF/m)
Nominal Capacitance, Conductor to Shield
56.4 pF/ft (185 pF/m)
Nominal Inductance, Conductor to Conductor
0.213 µH/ft (0.7 µH/m)
Nominal Inductance, Conductor to Shield
0.061 µH/ft (0.2 µH/m)
Nominal DC Resistance per Conductor
12.2 Ω/1,000 ft (40 Ω/km)
Nominal DC Resistance of Shield
6.1 Ω/1,000 ft (20 Ω/km)
Nominal Characteristic Impedance
93.5 Ω
Insulation Resistance, Conductor to Shield
Greater than 1 GΩ
Shipping
Box Dimensions
12.00" x 12.00" x 12.00"
Shipping Weight
10.00 lbs
Shipping Method
Parcel
Identifiers
UPC
019372410645
