Specifications
Certifications
Ingress Protection
IP-55
MilSpec Testing
Exceeded MilSpec819 (humidity, salt spray, temperature, UV)
Electrical Component Testing
Passed Mil-STD-202f (salt spray)
Enclosure UL Rating
F1-F2
Audio
Effective Frequency Range
55 Hz - 25 kHz
Rated Noise Power
80 W
Broadband Sensitivity
>84 dB @1 W/1M (500 - 5 kHz)
Coverage Angle (-6 dB)
180° (500 Hz – 5 kHz)
Maximum Continuous SPL
104 dB
Maximum Peak SPL
110 dB
Rated Impedance
16 Ω
Transformer Taps
7.5 W, 15 W, 30 W, 60 W / 15 W, 30 W, 60 W
Transducers
Woofer
5.25 in (135 mm) weather-resistant cone, ferrite magnet, rubber surround
Tweeter
(1) 1 in (25 mm) aluminum dome, rubber surround
Connectivity
Input Connector Type
Wire pig-tail, blunt
Construction
Enclosure Material
Glass-filled polypropylene, F1-F2 UL Rated
Grille Material
Polyester fabric on polycarbonate frame
Mount
Direct to concrete
Operating Environment
Outdoor use
Color
Green (paintable)
Dimensions
Product Dimensions (HWD)
30.16" (766 mm) x 6.46" (164 mm) x 6.46" (164 mm) (not including base support)
Shipping Dimensions (HWD)
38.23" (971 mm) x 10.63" (270 mm) x 10.63" (270 mm)
Weight
Net Weight
16.64 lbs (7.5 kg)
Shipping Weight
24.5 lbs (11.1 kg)
Included Items
Included Accessories
Direct-to-concrete mounting collar
