Specifications
Audio
Effective Frequency Range
55 Hz - 25 kHz
Rated Noise Power
80 W
Broadband Sensitivity
>84 dB @ 1 W/1m (200 - 10 kHz)
Coverage Angle (-6 dB)
360° (500 Hz – 5 kHz)
Maximum Continuous SPL
104 dB
Maximum Peak SPL
110 dB
Rated Impedance
16 Ω
Transformer Taps
7.5 W, 15 W, 30 W, 60 W / 15 W, 30 W, 60 W
Transducers
Woofer
5.31" weather-resistant cone, ferrite magnet, rubber surround (x1)
Tweeter
1" aluminum dome, rubber surround (x2)
Connectivity
Input Connector Type
Wire pig-tail, blunt
Construction
Enclosure Material
Glass-filled polypropylene, F1-F2 UL Rated
Grille Material
Polyester fabric on polycarbonate frame
Mount
Direct to concrete
Color
Green (paintable)
Certifications
Ingress Protection
IP-55
Testing
Exceeded MilSpec819 for humidity, salt spray, temperature, and UV; Passed Mil-STD-202f for salt spray
Dimensions
Product Dimensions (HWD)
30.16" x 6.46" x 6.46" (not including base support)
Shipping Dimensions (HWD)
38.23" x 10.63" x 10.63"
Weight
Net Weight
16.16 lbs (7.3 kg)
Shipping Weight
24.3 lbs (11 kg)
Included Items
Included Accessories
Direct-to-concrete mounting collar
