Q-SYS DTH1620 16-Channel Dante Network Amplifier Themed Entertainment

Q-SYS DTH1620 16-Channel Dante Network Amplifier Themed Entertainment

SoundPro Item: 92504 | Part Number: DTH1620

$4,200.00
$4,200.00 $4,200.00
Your Price Sold out
MSRP: $4,200.00 | MAP: $4,200.00

Usually ships in 5-7 business days

  • Ruggedized And Vibration Tested Construction Supports Mobile Attraction Deployments
  • Dante/AES67 Network Audio With Remote Control And Monitoring Capability
  • Molex Connectors On Speaker Outputs And Power Inputs Resist Vibration-Induced Failures
  • Class D Output Circuitry Supports Both Passive And Haptic Transducer Loads
  • Native Q-SYS Extension Enables Drag-And-Drop Control Without Custom Scripting
  • Dante Domain Manager Ready For Large-Scale Multi-Zone Network Audio Management
Log in or register for YOUR best price

The Q-SYS DTH1620 is a multi-channel network amplifier engineered specifically for themed entertainment environments — including theme park rides, parade floats, and mobile attractions — where high channel density, low power output, and mechanical durability are non-negotiable. With 16 channels at 20 watts per channel, it fills a distinct gap between consumer AV gear and rack-mount touring amplifiers, delivering purpose-built performance in a compact, vibration-tested chassis suited for embedded installation in moving vehicles and ride systems.

Dante and AES67 network audio connectivity positions the DTH1620 within modern IP audio workflows, allowing audio designers to route, monitor, and control channels across complex multi-zone attraction systems without analog infrastructure. Dante Domain Manager readiness extends scalability for large-venue operators managing multiple networked amplifiers across an entire park or facility.

For integrators working within the Q-SYS ecosystem, the available Q-SYS Extension enables native control and monitoring through TSC series touch screen controllers using drag-and-drop programming in Q-SYS Designer Software v8.4 or later — eliminating the need for custom scripting or third-party middleware. Support for both passive loudspeakers and haptic transducers extends the DTH1620's utility beyond traditional PA applications into immersive and experiential audio installations.

Downloads

View full details

Specifications

Audio
Frequency Response
20 Hz - 20 kHz @ 1 W into 8 Ω
Signal-To-Noise Ratio
97 dB (20 W into 8 Ω)
Output Circuitry
Class D
Channel Count
16
Power Per Channel
20 W
Connectivity
Mic/Line Inputs
Molex 6-pin, +24 V DC
Speaker Outputs
Molex 16-pin
Headphone/Volume Control
Molex 6-pin
Ethernet
RJ-45 with link and activity LED indicators
Power
Power Requirements (1/8 Power)
+24 V DC @ 3 A, all channels
Power Requirements (Full Power)
+24 V DC @ 17.5 A, all channels
Cooling
Fan with thermal speed control
Dimensions
Dimensions
9 x 6.7 x 2.0 in (229 x 169 x 51 mm)
Weight
Product Weight
2.4 lbs (1.1 kg)
