Q-SYS NVM-302E Network HDMI Video Encoder for AV Over IP

Q-SYS NVM-302E Network HDMI Video Encoder for AV Over IP

SoundPro Item: 206943 | Part Number: NVM-302E

$1,600.00
$1,600.00 $1,600.00
Your Price Sold out
MSRP: $1,600.00 | MAP: $1,600.00

In stock and ready to ship

  • Single-Channel Encode App Pre-Installed With License Path To Dual-Channel Output
  • Mediacast Routing Paradigm Enables Network-Efficient Video Distribution At Scale
  • Native Q-SYS Designer Configuration Eliminates Separate Matrix Or Management Hardware
  • HDCP 2.3 And 1.4 Support Ensures Compatibility With Protected Content Sources
  • RS-232 And IR Outputs Enable Third-Party Device Control Within Q-SYS
  • PoE+ And PoE++ Support Removes The Need For External Power Supplies
  • Software-Defined Architecture Supports Future Feature Updates And Additional Video Apps
Log in or register for YOUR best price

The Q-SYS NVM-302E is a network HDMI encoder built for systems integrators and AV designers who need to distribute high-quality video at scale across hospitality, government, entertainment, and collaboration environments. Unlike standalone encoders that require separate matrix or management hardware, the NVM-302E is configured entirely within Q-SYS Designer Software, enabling no-code deployment of hundreds of endpoints through a single unified environment that also handles DSP programming, AV routing, and control interface design.

The NVM-302E ships pre-installed with the NVM-E1 single-channel encode app, capable of streaming up to 4K60 4:4:4 from two switched HDMI 2.0 inputs. Integrators who require simultaneous dual-stream output can expand to the NVM-E2 app via license, delivering two independent 4K30 4:4:4 streams — one per input — without swapping hardware. The Mediacast AV routing paradigm provides network-efficient transport designed for large endpoint counts, and the platform is forward-compatible with select NV Series endpoints operating in Mediacast mode.

Powered by PoE+ or PoE++ with no external power supply required, the NVM-302E reduces rack infrastructure overhead and simplifies installation in space-constrained locations. RS-232 and IR outputs support third-party device control from within the Q-SYS ecosystem, and USB-C AV bridging is planned for a future firmware release — ensuring the hardware investment remains relevant as platform capabilities expand.

Downloads

View full details

Specifications

Video I/O
HDMI Inputs
2x HDMI 2.0, up to 4K60 4:4:4
HDMI Input Mode (NVM-E1 App)
2 inputs switched to single 4K60 4:4:4 stream (max)
HDMI Input Mode (NVM-E2 App)
Each input streamed to unique 4K30 4:4:4 streams (max)
HDCP Support
HDCP 2.3 and 1.4
USB-C Input
1x USB-C 3.1 Gen 2 (AV bridging enabled in future firmware release)
Audio I/O
HDMI Audio
8-channel PCM, Q-SYS routable
Connectivity
RS-232
2x RS-232 (3.5mm pitch euro-block)
IR Transmit
2x IR Transmit (3.5mm mini jack)
USB Type-C
USB 3.2 Gen 1 Type-C; Device Mode, Host Mode, and HID routing supported; AV Bridging in future firmware
USB Type-A
2x USB 3.2 Gen 1; HID routing supported
LAN
2.5GBASE-T compliant
Electrical
PoE+
802.3at Type 2, Class 4 — 25.5W at PD, 30W at PSE; 5V 300mA total for USB-A and USB-C
PoE++
802.3bt Type 3, Class 5 — 40W at PD, 45W at PSE; 5V 900mA total for USB-A and USB-C
Dimensions
Unit Dimensions
7.3" x 5.2" x 1.2" (185 x 131.5 x 30.5 mm)
Weight
Unit Weight
1.75 lbs (794 g)
Construction
Mounting Options
Surface mounting hardware included; compatible with NV-RK accessory for rack mounting
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Humidity
5 to 90% RH, non-condensing
Storage Temperature
-4° to 158° F (-20° to +70° C)
Included Items
In The Box
NVM-302E video endpoint, euro-terminal connectors for RS-232 and Aux Power, surface mounting accessories, safety and warranty statements
