Q-SYS NVM-E2 Dual 4K30 Network HDMI Encoder With License

Q-SYS NVM-E2 Dual 4K30 Network HDMI Encoder With License

SoundPro Item: 206944 | Part Number: NVM-E2

$2,195.00
$2,195.00 $2,195.00
Your Price Sold out
MSRP: $2,195.00 | MAP: $2,195.00

Usually ships in 5-7 business days

  • Dual-Channel Encode App Activated Via Included SLNVM-E2-P Software License
  • Mediacast Routing Delivers Network-Efficient Video Distribution Across Large Deployments
  • Native Q-SYS Designer Integration Eliminates Separate Video Matrix or Management Hardware
  • RS-232 And IR Transmit Ports Enable Third-Party Device Control From The Endpoint
  • PoE+ And PoE++ Compliance Simplifies Infrastructure By Powering Over Network Cable
  • HDCP 2.3 And 1.4 Support Ensures Compatibility With Protected Content Sources
  • Software-Defined Architecture Supports Future Feature Updates And Additional Video Apps
Log in or register for YOUR best price

The Q-SYS NVM-E2 is purpose-built for AV integrators and systems engineers deploying large-scale network video across hospitality, government, entertainment, and collaboration environments. Unlike single-purpose matrix hardware, it operates within the Q-SYS Full Stack AV Platform, meaning video routing, DSP, and control logic are managed from a single software environment — Q-SYS Designer — without requiring a separate video management layer.

The included SLNVM-E2-P software license activates the dual-channel NVM-E2 encode app, allowing each of the two HDMI 2.0 inputs to stream independently at up to 4K30 4:4:4. Audio from HDMI sources is carried as 8-channel PCM and remains fully routable within the Q-SYS ecosystem. RS-232 and IR transmit ports enable third-party device control directly from the endpoint, reducing the need for external control hardware at each display location.

Deployment at scale is handled through the NVM Designer tool, which supports no-code configuration of hundreds of endpoints natively in Q-SYS Designer Software. The NVM-302E hardware is PoE+ and PoE++ compatible, simplifying cabling infrastructure, and ships with surface mounting accessories while remaining compatible with the NV-RK rack accessory for structured installations.

Downloads

View full details

Specifications

Video I/O
HDMI Inputs
2x HDMI 2.0, up to 4K60 4:4:4 per input
HDMI Input HDCP
HDCP 2.3 and 1.4 supported
NVM-E1 App Max Output
Single 4K60 4:4:4 stream (switched)
NVM-E2 App Max Output
Dual independent 4K30 4:4:4 streams
USB-C Video Input
1x USB-C 3.1 Gen 2 (AV bridging enabled in future firmware)
Audio
HDMI Audio
8-channel PCM, Q-SYS routable
Connectivity
LAN
2.5GBASE-T compliant
RS-232
2x RS-232, 3.5mm pitch euro-block
IR Transmit
2x IR Transmit, 3.5mm mini jack
USB Type-C
USB 3.2 Gen 1 Type-C, Device and Host mode, HID routing supported
USB Type-A
2x USB 3.2 Gen 1, HID routing supported
Power
PoE+ Standard
802.3at Type 2, Class 4 — 25.5W at PD, 30W at PSE
PoE++ Standard
802.3bt Type 3, Class 5 — 40W at PD, 45W at PSE
USB Power (PoE+)
5V 300mA total for USB-A and USB-C ports
USB Power (PoE++)
5V 900mA total for USB-A and USB-C ports
Dimensions
Dimensions
7.3" x 5.2" x 1.2" (185 x 131.5 x 30.5 mm)
Weight
Unit Weight
1.75 lbs (794 g)
Environmental
Operating Temperature
32° to 104° F (0° to 40° C)
Storage Temperature
-4° to 158° F (-20° to +70° C)
Humidity
5 to 90% RH non-condensing
Included Items
In the Box
NVM-302E video endpoint, euro-terminal connectors for RS-232 and Aux Power, surface mounting accessories, safety and warranty statements
Software License
SLNVM-E2-P dual-encode expansion license
Identifiers
Mounting Accessory Compatibility
NV-RK rack mount accessory
