Q-SYS PL-DC12 12" Two-Way Passive Performance Loudspeaker | White

Q-SYS PL-DC12 12" Two-Way Passive Performance Loudspeaker | White

SoundPro Item: 204482 | Part Number: PL-DC12-WH

Pricing available upon request

Pricing available upon request

Your Price Sold out

Usually ships in 5-7 business days

  • Reconfigurable Rotatable Horn Enables Symmetrical Or Asymmetrical Coverage From One Cabinet
  • IP54 Weatherized Enclosure Supports Protected Outdoor And Indoor Permanent Installations
  • Neodymium LF Transducer Delivers High Output With Reduced Enclosure Weight
  • CX-Q Network Amplifier Integration Unlocks Custom Voicings For Faster System Commissioning
  • Multiple Mounting Options Accommodate Diverse Architectural And Venue Configurations
Log in or register for YOUR best price

The Q-SYS PL-DC12 targets AV integrators and system designers who need high-output, configurable loudspeaker coverage in permanent installed environments. The reconfigurable, rotatable half-horn assembly lets installers dial in symmetrical or asymmetrical dispersion patterns on-site, making a single enclosure viable as a stage fill, delay speaker, or front-of-house unit in smaller venues. This adaptability reduces SKU count on complex installs and simplifies project inventory across multi-zone facilities in entertainment, corporate, and higher education markets.

The IP54-rated weatherized enclosure sets the PL-DC12 apart from standard indoor-only point source cabinets in its class. Exterior plywood construction, stainless hardware, polyurea paint, UV- and corrosion-treated grille, and hydrophobic stainless steel mesh support protected outdoor deployments including covered amphitheaters, hospitality terraces, and stadium concourses. Input cup sealing is rated IP65, providing an additional layer of protection at the signal entry point.

Integration with Q-SYS CX-Q network amplifiers enables custom voicings and filter sets that accelerate commissioning and improve sonic consistency across distributed zones. A neodymium LF transducer delivers high output while keeping enclosure weight manageable for install teams. Multiple mounting options extend compatibility across ceiling, wall, and truss configurations, making the PL-DC12 a practical choice wherever architectural flexibility is required.

Downloads

View full details

Specifications

Environmental
Weatherization Rating
IP54
Input Cup Sealing
IP65
Weatherization Details
Exterior plywood, stainless screws, UV/corrosion-treated grille, hydrophobic stainless steel mesh, polyurea paint
Construction
Enclosure Material
Exterior plywood
Enclosure Configuration
Two-way, passive point source in bass-reflex enclosure
Transducers
LF Driver
12 in (320 mm), 3 in (75 mm) voice coil, neodymium
HF Driver
Compression driver, 3 in (75 mm) voice coil
Audio
System Sensitivity
102 dB @ 1 W/1 m
Max SPL (Continuous)
124 dB
Coverage
Symmetrical Patterns
90° x 50°, 70° x 50°, 110° x 50°
Asymmetrical Patterns
100° x 50°, 90° x 50°, 80° x 50°
Compatibility
Recommended Amplifiers
Q-SYS CX-Q 8K4 (up to 2 per ch), Q-SYS CX-Q 4K4 (up to 1 per ch)
Identifiers
Color
White
