Q-SYS Server Core X10 Network I/O Processor

Q-SYS Server Core X10 Network I/O Processor

SoundPro Item: 151942 | Part Number: SERVER CORE X10

$8,650.00
$8,650.00 $8,650.00
Your Price Sold out
MSRP: $8,650.00 | MAP: $8,650.00

Usually ships in 5-7 business days

  • 256 x 256 networked audio channels (Q-LAN / AES67)
  • 64x AEC channels @ 200 ms
  • Includes 8 x 8 Software-based Dante channels (licensable up to 128 x 128)
  • Supports up to sixteen (16) Q-SYS NM-T1 tabletop microphones
  • Up to 32 VoIP softphone instances
  • 64 x 64 Media/WAN channel capacity
  • 16 multitrack playback channels (up to 128 with optional stackable feature license)
  • 4 multitrack record channels
  • Two (2) 2.5 Gbps Ethernet ports for redundant networked audio
  • Two (2) 2.5 Gbps independent, auxiliary Ethernet ports for segregation of network services such as VoIP, SNMP, LLDP, LDAP and WAN Media streaming
  • Onboard 256 GB media drive
  • 1 RU form factor
Log in or register for YOUR best price

The Server Core X10 combines the Q-SYS Full Stack AV Platform with enterprise-grade server hardware to deliver a flexible and scalable audio, video and control solution for medium and large scale applications. The Server Core X10 functions effectively as a central processor for multiple zones or spaces with distributed network I/O or paired with distributed processing.

View full details

Specifications

Q-SYS CAPACITIES
Total Network I/O Channels
256 x 256
Total Network I/O Streams
128 x 128
Dante Network I/O
8 x 8 included; up to 128 x 128 with Software-based Dante feature license
Media/WAN Channel Capacity
64 x 64
VoIP Softphones
32
AEC Channels (200 ms tail length)
64
Audio Recording / Playback
4 channels recording; 16 channels playback; expandable up to 128 channels playback with optional multi track playback license (SLMTP-32); stackable up to 4x
Media Drive Capacity
256 GB; at least 200 GB available for user media; at least 400 hours of uncompressed 48 kHz 24 bit mono WAV format audio files
HARDWARE
Power
1x universal input; 500 W PSU module
LAN
4x 2500 Mbps ports; 2x Q-SYS Multimedia; 2x Q-SYS Aux
RS232
1x DB-9 RS-232 port (rear panel); 16550-compliant
USB
2 USB-A; 2 USB-C
Ventilation
Forced air; front intake; rear exhaust
CONTROLS & INDICATORS
Front Indicators
Power LED; Front Panel LCD module (white backlight)
Navigation Controls
4 navigation buttons (up, down, left, right); 1 selection button
PACKAGING & ACCESSORIES
Product Dimensions (L x W x H)
18.11 x 17.24 x 1.73 in (460 x 438 x 44 mm)
Product Weight
18.7 lb (8.5 kg)
Shipping Carton Dimensions (L x W x H)
24.0 x 22.0 x 8.0 in (610 x 559 x 203 mm)
Shipping Weight
28.1 lb (12.7 kg)
Included Accessories
Rail kit; Safety information & regulatory statements pamphlet; 1x region-specific power cord; Rack ear handles
MISCELLANEOUS
Line Voltage
100-240 VAC; ~50/60 Hz
Current Draw
2.0 A
Operating Temperature Range
0°C to +40°C
Storage Temperature
-40°C to +70°C
BTU/Hour
136 BTU/Hr
Humidity
10% to 85%
Regulatory
FCC 47 CFR Part 15 Subpart B; Canada ICES-003; EN 55032; EN 55035; EU RoHS directive 2011/65/EU; WEEE directive 2012/19/EU; REACH; China RoHS GB/T26572; RCM; IEC/EN/UL 62368-1
Battery Chemistry
Lithium Carbon Monofluoride
