QSC AD-P.SUB AcousticDesign 6.5-Inch Dual Voice Coil Pendant Subwoofer | Color: Black
QSC AD-P.SUB AcousticDesign 6.5-Inch Dual Voice Coil Pendant Subwoofer | Color: Black
SoundPro Item: 15458 | Part Number: AD-P.SUB-BK
Pricing available upon request
Pricing available upon request
Usually ships in 5-7 business days
- Dual voice coil for improved thermal dissipation and higher output
- Low saturation and low-loss 70 / 100 V transformers with 4 Ω bypass
- 4x built-in high-pass filtered outputs
- Snap-fit magnetic grills
- Locking 4-pole Euroblock connectors
- 2x quick link cable assemblies and slip-lock fasteners supplied
- Intrinsic Correction™ voicings available via MP-M Series mixers and Q-SYS Platform, including the CXD-Q Series amplifiers
- UL1480 certified
The AD-P.SUB is a pendant subwoofer compatible with up to four satellite speakers from the SUB/SAT line.
Deliver refined depth and clarity even at lower volume settings. Part of QSC’s AcousticDesign™ Series, the AD-P.SUB’s 6.5” weather-treated paper cone woofer on a dual voice-coil improves thermal dissipation and higher output while keeping it within a small form factor. Among its many features, Intrinsic Correction™ voicings can be deployed to optimize installation and performance.
Maintain an accurate frequency response even in 70/100V applications. The AD-P.SUB’s low-loss, low-saturation 30-watt transformer offers selectable taps (including 4Ω bypass) and incorporates a rotary selector under the magnetic snap-fit steel grille.
In addition to its durable powder-coated steel back can, the AD-P.SUB boasts a rugged ABS baffle that uses UV inhibitors to prevent discoloration. The magnetic grille has a removable logo ideal for non-branded installations. Two quick-link cable assemblies and slip-lock fasteners are included to streamline setup. Its conduit cover plate can be removed to access its locking 4-pole Euro-block connectors capable of 12AWG (2mm) wire thickness.
AcousticDesign speakers are free of obtrusive branding. They’re available in black or white, as well as paintable to match any décor.
More about QSC’s AcousticDesign Series
Easy installation, flexible mounting options, and rugged, high-weather resistance are just three of the features that set QSC’s AcousticDesign™ series apart. These premium loudspeakers are designed to give contractors and integrators versatile, reliable solutions for permanent sound installations. Unified by premium audio quality and consistent tonal characteristics this series is comprised of ceiling, surface, and pendant alternatives ideal for environments where you need the perfect combination of performance, coverage, and aesthetic appeal.
