Q-SYS MPA-Q 8x125 Network Amplifier With 8 Channels

Q-SYS MPA-Q 8x125 Network Amplifier With 8 Channels

SoundPro Item: 204395 | Part Number: MPA-Q 8X125

Pricing available upon request

Pricing available upon request

Your Price Sold out

In stock and ready to ship

  • Eight Output Channels For Flexible Zone Design
  • Direct Drive 70V/100V On All Channels
  • Dual Ethernet Ports For Network Redundancy
  • Analog Fallback Helps Maintain Audio Service
  • PoE Support Speeds Recovery After Outages
  • GPI And Relay I/O For System Control
  • Rack Or Surface Mount Hardware Included
Log in or register for YOUR best price

The Q-SYS MPA-Q 8x125 is an eight-channel network amplifier designed for distributed and performance audio systems that need native integration within the Q-SYS ecosystem. It supports Lo-Z, Hi-Z, 70 V, and 100 V direct drive on every channel, allowing system designers to handle mixed speaker loads without relying on manual switching. With eight routable analog line-level inputs and dual gigabit Ethernet ports, it fits applications where networked audio transport and local source access both matter.

This model is well suited to hospitality, entertainment, retail, and government installations where uptime and operational flexibility are critical. Standalone mode enables the amplifier to switch to available analog inputs if network connectivity is lost, while PoE support on LAN A helps restore audio quickly after a power interruption. Four GPI inputs and two NO/NC relays also give integrators additional control options for automated system behavior.

The 2RU full-rack chassis includes hardware for rack or surface mounting, making deployment easier across centralized equipment racks and space-limited installation environments. Analog Mode can bypass networked audio entirely, creating a fully analog amplifier with basic channel setup available from the front panel display.

View full details

Specifications

Audio Performance
Freq response @ 20Hz-20kHz, 8Ω
+0.2 dB / -0.7 dB
Output THD+N @1kHz
0.01%-0.03% typical; 1% max
SNR @ 20Hz-20kHz, 8Ω, A-weighted
>112 dB
Gain @+4dBu input
28 dB
Damping factor
>160
Input dynamic range (unweighted)
>108 dB
Input impedence (balanced & unbalanced) @ 1kHz
>11k balanced and >5.5k unbalanced
Sample rate
48 kHz
DSP Processing
Gain, Polarity, IIR Filters (HPF, Parametric, Shelf, Array Correction), FIR Filters (1024 taps per channel), Delay (up to 2020 milliseconds per channel), Limiters (narrow-band, RMS, and peak limiters)
Output Power
All channels driven A, B, C, D, E, F, G, H
75 W
70 V
75 W
8 Ω
75 W
4 Ω
75 W
2 Ω
75 W
Single channel driven A or B or C or D or E or F or G or H
75 W
2 channels bridged A+B or C+D or E+F or G+H
150 W
70 V
150 W
8 Ω
150 W
4 Ω
150 W
2 Ω
Not supported
Environmental
Operating temperature range
32° to 104° F (0° - 40° C)
Storage temperature range
-4° to 158° F (-20° to +70° C)
Humidity range
5% - 85% RH
Connections And Control
Audio I/O connections
Output: 8x channels (Euro 7.62 mm) Input: 8x channels(Euro 3.5 mm)
Networking
2x 1 Gbps Ethernet ports LAN A optionally accepts PoE (802.3af Type 1) for quick time-to-audio following a power interruption
GPI
0-3.3V DC Closure
Mounting options
Front rack ears come installed for rack mount installation (rack ears can also be used for chassis-supported surface-mounting)
AC power input
100-240 V, 50/60 Hz, 3.2-2.0 A
Physical
Product dimensions (L x W x H)
15.0 x 19.0 x 3.5 in (381 x 483 x 89 mm)
Product weight
22.5 lbs (10.2 kg)
Included accessories
1x AC mains power cord (country specific) Removable rack ears for rack- or surface-mounting 4-position 7.62mm pitch Euroblock connectors (Qty 8) 3-position 3.5mm pitch Euroblock connectors (Qty 16) 12-position (2-row) 3.5mm pitch Euroblock connector (Qty 1)
