Q-SYS MPA-Q 8x250 8-Channel Network Amplifier 2RU

Q-SYS MPA-Q 8x250 8-Channel Network Amplifier 2RU

SoundPro Item: 204396 | Part Number: MPA-Q 8X250

Pricing available upon request

Pricing available upon request

Your Price Sold out

In stock and ready to ship

  • Native Q-SYS Integration For Unified System Control
  • Dual Ethernet Ports Support Network Redundancy
  • Analog Fallback Helps Maintain Audio Continuity
  • Analog Mode Enables Operation Without Network Audio
  • 2RU Chassis Fits Standard Rack Installations
  • Included Mounting Hardware Simplifies Deployment
Log in or register for YOUR best price

The Q-SYS MPA-Q 8x250 is an 8-channel network amplifier designed for distributed and performance-focused installed audio systems that need native integration with the Q-SYS platform. It supports low-impedance and constant-voltage loudspeaker deployments from the same amplifier architecture, making it suitable for hospitality, retail, entertainment, and government environments where system flexibility and centralized control matter. Dual gigabit Ethernet ports support networked audio resilience, while the 2RU full-rack chassis fits standard equipment rooms and AV racks.

For integrators building systems that must keep passing audio during interruptions, the amplifier includes standalone operation with the ability to switch to available analog inputs if network connectivity drops. LAN A can accept PoE for quick time-to-audio after a power event, helping restore signal flow faster in critical paging and background music applications. Analog Mode also allows the unit to function as a fully analog amplifier, with basic channel setup available from the front panel display.

Beyond amplification, the platform includes onboard DSP and control connectivity for broader system design needs. Eight line-level analog inputs, four GPI inputs, and two NO/NC relays provide useful integration points for control logic and source routing. Included rack and surface-mount hardware, plus Euroblock connectivity, support clean installation workflows in commercial AV projects.

View full details

Specifications

Audio Performance
Freq response @ 20Hz-20kHz, 8Ω
+0.2 dB / -0.7 dB
Output THD+N @1kHz
0.01%-0.03% typical; 1% max
SNR @ 20Hz-20kHz, 8Ω, A-weighted
>112 dB
Gain @+4dBu input
31 dB
Damping factor
>160
Input dynamic range (unweighted)
>108 dB
Input impedence (balanced & unbalanced) @ 1kHz
>11k balanced and >5.5k unbalanced
Sample rate
48 kHz
DSP
DSP Processing
Gain, Polarity, IIR Filters (HPF, Parametric, Shelf, Array Correction), FIR Filters (1024 taps per channel), Delay (up to 2020 milliseconds per channel), Limiters (narrow-band, RMS, and peak limiters)
Output Power
All channels driven A, B, C, D, E, F, G, H
150 W
70 V
150 W
8 Ω
150 W
4 Ω
150 W
2 Ω
150 W
Single channel driven A or B or C or D or E or F or G or H
150 W
2 channels bridged A+B or C+D or E+F or G+H
300 W
70 V
300 W
8 Ω
300 W
4 Ω
300 W
2 Ω
Not supported
Environmental
Operating temperature range
32° to 104° F (0° - 40° C)
Storage temperature range
-4° to 158° F (-20° to +70° C)
Humidity range
5% - 85% RH
Connections And Networking
Audio I/O connections
Output: 8x channels (Euro 7.62 mm) Input: 8x channels (Euro 3.5 mm)
Networking
2x 1 Gbps Ethernet ports LAN A optionally accepts PoE (802.3af Type 1) for quick time-to-audio following a power interruption
GPI
0-3.3V DC Closure
Power And Installation
Mounting options
Front rack ears come installed for rack mount installation (rack ears can also be used for chassis-supported surface-mounting)
AC power input
100-240 V, 50/60Hz, 5.2-2.8 A
Product dimensions (L x W x H)
15.0 x 19.0 x 3.5 in (381 x 483 x 89 mm)
Product weight
22.9 lbs (10.4 kg)
Included accessories
1x AC mains power cord (country specific) Removable rack ears for rack- or surface-mounting 4-position 7.62mm pitch Euroblock connectors (Qty 8) 3-position 3.5mm pitch Euroblock connectors (Qty 16) 12-position (2-row) 3.5mm pitch Euroblock connector (Qty 1)
