Q-SYS QIO-ML24i High-density Audio Expander

Q-SYS QIO-ML24i High-density Audio Expander

SoundPro Item: 201771 | Part Number: QIO-ML24i

$3,715.00
$3,715.00 $3,715.00
Your Price Sold out
MSRP: $3,715.00 | MAP: $3,715.00

In stock and ready to ship

  • Native, high-density audio I/O for Q-SYS
  • Twenty-four (24) mic/line level inputs
  • Supports both network and peripheral redundancy
  • 1RU form factor
  • 8 x 8 GPIO to integrate third-party device control connectivity
  • Configurable +48 VDC phantom power on inputs
  • Microphone detection on inputs enables monitoring, usage statistics, and failure notifications
  • Integrated relay mute on outputs enables redundant audio output for peripheral redundancy and prevents power-up transients
  • Two (2) gigabit Ethernet ports for redundant networked audio
  • Surface- or rack-mountable
  • QIO-CK redundancy cable kit (sold separately)
Log in or register for YOUR best price

The Q-SYS QIO Series network audio expanders enable interoperability with non-networked audio I/O to expand the power of Q-SYS across more devices. The QIO-ML24i, QIO-L24o and QIO-24f address the I/O needs of larger systems with a single peripheral rather than multiple smaller devices, making them ideal for applications such as event productions, large hospitality installations, paging systems, judicial spaces and more.

View full details

Specifications

CONNECTIVITY
Audio Channels
24 mic/line inputs
MIC/LINE INPUTS
Maximum Input Level
+24 dBu (balanced); +18 dBu (unbalanced)
Preamplifier Gain Range
0 dB to 60 dB
Input Sensitivity Range
-36 dBu to +24 dBu
Phantom Power
+48 VDC
Input Impedance
10 kΩ (balanced); 5 kΩ (unbalanced)
Equivalent Input Noise
<-123 dBu; no weighting; 20 Hz - 20 kHz
Input Crosstalk @ 1 kHz
>110 dB typical; >95 dB max
Input Dynamic Range
>111 dB (+24 dBu sensitivity); >110 dB (+10 dBu sensitivity); >106 dB (-10 dBu sensitivity); >86 dB (-36 dBu sensitivity)
PHYSICAL
Dimensions (L×W×H)
12.0 x 17.4 x 1.72 in; 304.8 x 443.0 x 43.6 mm
Weight
8.5 lb; 3.86 kg
Mounting Options
Surface- or rack-mountable; 1RU; full-rack width
ACCESSORIES
Included Accessories
1x AC mains power cord (country-specific); removable rack ears
Optional Accessories
QIO-CK redundancy cable kit (sold separately)
CONNECTORS
Power Supply Input
1x universal input; 100-240 V; 50/60 Hz
AC Input Rating
65 W max
LAN
2x gigabit Ethernet connectors; does not provide or accept PoE
ENVIRONMENTAL
Operating Temperature
32° to 122° F; 0° to 50° C
Storage Temperature
-4° to 158° F; -20° to 70° C
Humidity
5% to 85%; non-condensing
Thermal Dissipation
222 BTU/h
COMPLIANCE
Regulatory
FCC 47 CFR Part 15 Subpart B; Canada ICES-003; EN 55032; EN 55035; EU RoHS directive 2011/65/EU; WEEE directive 2012/19/EU; REACH; China RoHS GB/T26572; RCM; IEC/EN/UL 62368-1
