Quam MA/E9/S2/T8 617 CID Sound Masking Speaker Assembly

Quam MA/E9/S2/T8 617 CID Sound Masking Speaker Assembly

SoundPro Item: 10763 | Part Number: MA/E9/S2/T8

$127.30
$127.30 $127.30
Your Price Sold out
MSRP: $127.30 | MAP: $127.30

Usually ships in 5-7 business days

  • Upward-facing installation on 24" wide ceiling tile on conventional suspended ceiling grid
  • 3.5" high x 23.75" wide x 11.8" deep
  • Speaker weighs 7 pounds
Log in or register for YOUR best price

This 617 CID, ceiling grid mount, sound masking loudspeaker assembly consists of an 8″ O.D., dual cone loudspeaker with a 10 oz. magnet and a 4W, 70V rotary select transformer. Support chain is supplied.

View full details
  • APPLICATION
    • Intended Use: Indoor environment
    • Program Material: Equalized random noise
    • Secondary Use: Signal tones or equalized voice
    • Installation: Placed upward-facing on 24" wide ceiling tile on conventional suspended ceiling grid
  • AUDIO PERFORMANCE
    • Average Sensitivity: 95dB SPL, 1W/1M
    • Loudspeaker Power Rating: 20W RMS, EIA 426A Standard
    • Calculated Output: 101dB SPL, 4W/1M
    • Magnet Type & Weight: BeFe Ceramic, 10 oz.
    • Frequency Response: 65Hz - 17kHz, EIA 426A Standard
    • Nominal Coverage Angle: 100° Included Angle, -6dB/2kHz, Half Space
    • Audio Connection: 7", Color-coded, Pre-cut and Tinned Leads
    • Mechanical Connection: Seismic tie-offs provided on top of unit if required by AHJ
  • COMPONENT
    • Unit Dimension: 3 7⁄16" (H) x 23 ¾" (W) x 11 13⁄16" (D) x
    • Weight: 7 lbs
    • Loudspeaker Model: 8C10PAX
    • Loudspeaker Specs: 8" O.D., dual cone loudspeaker, 10 oz. magnet
    • Transformer: 4W, 25/70V, rotary select with 5 taps (0.25W, 0.50W, 1W, 2W, 4W)
