Specifications
Dimensions
Dimensions (HxWxD)
11 5⁄8 x 11 5⁄8 x 4 1⁄8 "
Weight
Magnet Type & Weight
BeFe Ceramic, 5 oz. Nominal
Audio
Average Sensitivity
96dB SPL, 1W/1M
Frequency Response
350Hz - 10kHz, EIA 426A Standard
Connectivity
Calculated Output
108dB SPL, 16W/1M
Audio Connection
7, Color-coded, Pre-tinned Leads
Construction
Program Material
Signal tones, voice and music
Transformer
16W, 25/70V, with 5 taps (1W, 2W, 4W, 8W, 16W)
Enclosure
SE1WVP
Finish
White powder coat finish
Shipping
Weight
12 lbs
General
Intended Use
Indoor or protected outdoor environment
Installation
Vertical or horizontal surface mount
Loudspeaker Power Rating
16W RMS, EIA 426A Standard
Nominal Coverage Angle
90° Included Angle, -6dB/2kHz, Half Space
Loudspeaker Model
H16
Loudspeaker Specs
Double re-entrant horn
Baffle
BS8VP: square
Other
Tamper resistant, 8-32x1 ‘pin-in-torx’ hardware included
