Specifications
Dimensions
Size (LxWxD)
121x6x147mm (4.5x2x6”)
Audio
Audio Circuit Type
High current balanced active output device
Frequency Response
20Hz-20kHz
Total Harmonic Distortion
0.007% @ -6dBFS
Output Impedance
150Ω
Sample Rate
44.1kHz, 48kHz, 88.2kHz, and 96kHz
Output Connectors
2x XLR male, 1x 3.5mm & 2x 1/4” headphone out
Connectivity
Input Connectors
2x XLR male, 1x 3.5mm & 2x 1/4” headphone out
Construction
Gain
+18dBu max @ 0dBFS
Construction
14-gauge steel
Finish
Durable powder coat
General
Dynamic Range
>100dB
Extras
Bit Depth: 24 bit; Idle Channel Noise:-108dB; Channel Separation: >75dB; Power Consumption: 1.25W; Power over Ethernet (PoE): Class 1 IEEE 802.3af
Conditions
For use in dry locations only between 5°C and 40°C
RF
Number of Channels
2
Power
Power
15VDC 400mA (included) or PoE
