Specifications
Dimensions
Size (LxWxD)
5x6.25x2" (127x159x51mm)
Electrical
Voltage Gain
+37.8dB
Audio
Audio Circuit Type
Active circuit
Frequency Response
RIAA response curve for phonographic playback
Total Harmonic Distortion
0.002% @ 1kHz (-33dBu input level)
Input Impedance
47k Ohms, unbalanced
Output Impedance
XLR out: 600 Ohms; ¼", 3.5mm, RCA outs: 470 Ohms
Output Connectors
RCA, 1/4", 3.5mm, XLR
Connectivity
Equivalent Input Noise
-82dBu @ 0dBu output
Maximum Input
-30dBu @ 1kHz
Input Connectors
RCA
Construction
Construction
14-gauge steel chassis and outer shell
Shipping
Weight
2.8 lbs (1.28 kg)
General
Dynamic Range
91dB
Intermodulation Distortion
0.025% @ -45dBu input
Extras
Rumble Filter
Conditions
For use in dry locations only between 5°C and 40°C
RF
Number of Channels
Stereo
Power
Power
+48V phantom or +15VDC/400mA external supply (included)
