Specifications
Dimensions
Dimensions (L X W X D)
4.25 x 2.75 x 1.75 inches (108 x 70 x 44mm)
Audio
Audio Circuit Type
Proprietary analog circuit with low-noise op-amp
Frequency Response
20Hz ~ 20kHz (± 1.5 dB
Total Harmonic Distortion
0.001% @ 0 dBu
Input Impedance
220kΩ - ¼" input
Output Impedance
600Ω - XLR output
Connectivity
Equivalent Input Noise
-86dBu
Maximum Input
+9dBu
Construction
Construction
14-gauge steel
Shipping
Weight
1.2 lb (0.54kg)
General
Dynamic Range
99dB
Intermodulation Distortion
0.002% @ 0 dBu
Phase Deviation
+28º at 20Hz | +1º at 1kHz | -2º at 20kHz
Noise
-82dB below 0dBu
Conditions
For use in dry locations only between 5°C and 40°C
Power
Power
48V phantom - proprietary digital switching
