Specifications
Dimensions
Dimensions (L X W X D)
3.25 x 5 x 1.875 inches
Weight
Shipping Weight
2.6 lbs (1.2 kg)
Audio
Audio Circuit Type
Passive, transformer based
Frequency Response
20Hz ~ 18.5KHz (± 0.2dB)
Total Harmonic Distortion
0.01% from 20Hz~20kHz @-10dB
Input Impedance
140k Ohms, unbalanced
Output Impedance
150 Ohms, balanced
Output Connectors
XLR
Connectivity
Maximum Input
+18dB @ 20Hz
Input Connectors
1/4", RCA, 3.5mm TRS
Construction
Transformer
Eclipse ET-DB2, 12:1 ratio
Construction
14-gauge steel chassis & shell
Shipping
Weight
1.8 lbs (0.82kg)
Shipping Size (L X W X D)
4.00 x 3.00 x 6.50 inches (102 x 76 x 165mm)
General
Dynamic Range
128dB
Phase Deviation
1° @ 100Hz; 8° @ 20Hz
Features
Ground lift
Conditions
For use in dry locations only between 5°C and 40°C
RF
Number of Channels
Dual channel (stereo)
Power
Power
Passive, no power required
