Radial SGI Stereo TX Transmitter With Jensen Transformer

Radial SGI Stereo TX Transmitter With Jensen Transformer

SoundPro Item: 202537 | Part Number: R800 1800 01

$269.99
$269.99 $269.99
Your Price Sold out
MSRP: $269.99 | MAP: $269.99

Usually ships in 5-7 business days

  • Premium Jensen Transformer Delivers Flat 20Hz To 18kHz Response With Minimal Distortion
  • Cat 5 Ethernet Transmission Extends Dual Instrument Signals Up To 300 Feet
  • Dual Thru-Outputs Enable Local Amp Connection Without Unplugging Transmission Path
  • Universal 9-18V DC Input Accepts Standard Pedalboard Power Supplies
  • 14-Gauge Steel Construction Provides Road-Ready Durability For Touring Applications
Log in or register for YOUR best price

The SGI Stereo TX transmitter solves the signal degradation problem inherent in long unbalanced cable runs between stages, studio rooms, or broadcast positions. Designed for touring guitarists, keyboard players, and install integrators who need to maintain pristine audio quality over extended distances, this unit pairs with the SGI RX receiver to deliver dual instrument channels up to 300 feet via readily available Cat 5 cable. The premium Jensen transformer ensures flat frequency response across the audio spectrum while rejecting interference that typically plagues lengthy 1/4-inch runs.

Dual thru-outputs provide immediate access to local amplifiers or direct boxes without disconnecting from the transmission path, streamlining stage and studio workflows. The left thru-output automatically sums both channels when only one connection is made, offering flexible mono monitoring options. Universal 9-18V DC compatibility accepts standard pedalboard power supplies, while the robust 14-gauge steel chassis withstands the demands of professional road use and permanent installations.

Downloads

View full details

Specifications

Audio Performance
Frequency Response
20Hz - 18kHz, ±1dB
Dynamic Range
>103.4dB @ -20dBV, 20kHz BW
Total Harmonic Distortion
<0.0052% @ -20dBu, 1kHz, 22Hz - 22kHz
Intermodulation Distortion
<0.024% 60Hz/7kHz, 4:1, +4dBu
Total Harmonic Distortion + Noise
<0.0056% @ -20dBu, 1kHz, 22Hz - 22kHz
Signal To Noise Ratio
>91dB re -20dBu, 1kHz
Maximum Input
>8.28dBu @ 1% THD+N, 1kHz, unbalanced
Cross Talk
<-32.7dB @ -20dBu, 10kHz
Input Impedance
200k?
Output Impedance
1.3k?
Connectivity
Input Connectors
2x 1/4" TS
Output Connectors
2x 1/4" TS, etherCON locking RJ45
Power
Power Requirement
±9-18VDC compatible
Power Supply Included
15VDC
Construction
Chassis Material
14-gauge Steel
Finish
Durable Powder Coat
Dimensions
Product Width
3.3"
Product Length
5"
Product Height
1.8"
Environmental
Operating Temperature
5°C to 40°C
Location Rating
Dry locations only
Shipping
Package Weight
2.35 lbs
Package Width
4.75"
Package Length
11.75"
Package Height
2.5"
Warranty
Warranty Coverage
Radial 3-year, transferable
