Specifications
Audio
Audio Circuit Type
Discrete Class-A FET input with low noise ICs
Frequency Response
20Hz ~ 18kHz
Dynamic Range
85dB
Gain
Unity gain device
Total Harmonic Distortion
0.05% @ -15dBu
Intermodulation Distortion
0.2% @ -20dBu
Input Impedance
220K Ohms input A, 220K/10M Ohms input B
Output Impedance
300 Ohms at XLR
Equivalent Input Noise
-92dBu at XLR
Noise Floor
-100dB
Maximum Input
+7 dBu
Connectivity
Input Connectors
1/4"
Output Connectors
1/4", XLR
Controls
Features
180° polarity reverse, ground lift, HPF, boost
Construction
Material
14 gauge steel
Dimensions
Size (L x W x D)
5.5" x 4.2" x 2"
Weight
Product Weight
2.55 lbs
Power
Power Supply
+15VDC/400mA adapter included
Environmental
Operating Conditions
Dry locations only, 5°C to 40°C
Certifications
Warranty
Radial 3-year, transferable
Shipping
Package Weight
3.35 lbs
Package Dimensions
11" x 5" x 2.75"
Identifiers
UPC
N/A
