- Audio Circuit Type100% discrete class-A
- Frequency Response20Hz - 15,000Hz (±1dB)
- Signal to Noise Ratio88dB below instrument level (-20dBu)
- Dynamic Range119 dB
- Noise FloorOUT-1 -110dB; OUT-2 -108dBu
- Max. Input+22dBu
- THD0.02% @ -15dBu
- Inter-Modulation Distortion0.02% @-20dBu
- Input Impedance600 Ω
- XLR Inputbalanced line-level, AES standard (pin-2 hot)
- Ground Lift (input)disconnects pin-1 at the XLR input
- Output Leveladjustable
- Output Typehigh-Z instrument level, out-1 direct, out-2 transformer isolated
- Polarity180° polarity reverse on Out-2
- Power+15VDC/400mA adapter included
- Construction14 gauge steel chassis & outer shell, powdercoat finish
- Dimensions5x2.75x10.75"
- Weight1.55 lbs
