Specifications
Certifications
Safety Compliance
CE compliant
General Specifications
Nominal Diameter
15 inch / 381 mm
Rated Impedance
8 ohm
Minimum Impedance
6.3 ohm
Program Power
1600 W
Power Handling Capacity
800 W
Sensitivity
97.0 dB
Frequency Range
30 - 1500 Hz
Effective Piston Diameter
340 mm / 13.39 inch
Max. Excursion Before Damage
50 mm / 1.97 inch
Voice Coil Diameter
4.0 inch / 102 mm
Voice Coil Winding Material
Copper
Voice Coil Length
23 mm / 0.91 inch
Number Of Layers
2
Kind Of Layers
inside/outside
Top Plate Thickness
14 mm / 0.55 inch
Cone Design
Straight
Surround Material
Polycotton
Surround Design
Triple roll
Magnets
Ceramic
Dual-Force Air Ventilation
Yes
Spider
03
Thiele-Small Parameters
Resonance Frequency (Fs)
36 Hz
DC Resistance (Re)
4.80 ohm
Mechanical Factor (Qms)
7.50 Qms
Electrical Factor (Qes)
0.27 Qes
Total Factor (Qts)
0.25 Qts
Bl Factor
24.80 T x m
Effective Moving Mass (Mms)
150.0 g
Equivalent Air Load (Vas)
160.0 liters
Effective Piston Area (Sd)
0.090 m2
Max. Linear Excursion (Xmax)
8 mm
Voice Coil Inductance @ 1kHz (Le1k)
1.20 mH
Half-Space Efficiency (Eff)
2.60%
Dimensions
Overall Diameter
393 mm / 15.47 inches
Height
159 mm / 6.26 inches
Bolt Circle Diameter
371-376 mm / 14.61-14.8 inch
Bolt Hole Diameter
7 mm / 0.28 inch
Front Mount Baffle Cut-Out
352 mm / 13.86 inch
Rear Mount Baffle Cut-Out
360 mm / 14.17 inch
Volume Occupied By Driver
4.3 liters / 0.17 ft3
Weight
Product Weight
13.5 kg / 29.76 lbs
Shipping
Package Height
195 mm / 7.68 inches
Package Width
420 mm / 16.54 inches
Package Depth
425 mm / 16.73 inches
Package Weight
15.5 kg / 34.17 lbs
