Specifications
Certifications
Safety Agency
CE compliant
Performance
Nominal Diameter
10 inch / 254 mm
Rated Impedance
8 ohm
Minimum Impedance
6.4 ohm
Program Power
600 W
Power Handling Capacity
300 W
Sensitivity
98.5 dB
Frequency Range
55 - 3000 Hz
Effective Piston Diameter
210 mm / 8.27 inch
Max. Excursion Before Damage
40 mm / 1.57 inch
Thiele-Small Parameters
Resonance Frequency (Fs)
76 Hz
DC Resistance (Re)
5.20 ohm
Mechanical Factor (Qms)
8.00
Electrical Factor (Qes)
0.35
Total Factor (Qts)
0.34
Bl Factor
14.90 T x m
Effective Moving Mass (Mms)
33.0 g
Equivalent Air Volume (Vas)
24.0 liters
Effective Piston Area (Sd)
0.040 m2
Max. Linear Excursion (Xmax)
7 mm
Voice Coil Inductance @ 1kHz (Le1k)
0.50 mH
Half-Space Efficiency (Eff)
2.71%
Construction
Voice Coil Diameter
2.5 inch / 63 mm
Voice Coil Winding Material
Aluminum
Voice Coil Length
18 mm / 0.71 inch
Number Of Layers
2
Kind Of Layers
inside/outside
Top Plate Thickness
8 mm / 0.31 inch
Cone Design
Curved
Surround Material
Polycotton
Surround Design
M-roll
Magnets
Ceramic
Spider
01
Color
Black
Dimensions
Height
123 mm / 4.84 inches
Diameter
260 mm / 10.24 inches
Mounting
Overall Diameter
260 mm / 10.24 inches
Bolt Circle Diameter
241-246 mm / 9.49-9.69 inch
Bolt Hole Diameter
6 mm / 0.24 inch
Front Mount Baffle Cut-Out
232 mm / 9.13 inch
Rear Mount Baffle Cut-Out
232 mm / 9.13 inch
Volume Occupied By Driver
1.2 liters / 0.05 ft3
Weight
Product Weight
5 kg / 11.02 lbs
Shipping
Package Height
180 mm / 7.09 inches
Package Width
290 mm / 11.42 inches
Package Depth
290 mm / 11.42 inches
Package Weight
5.5 kg / 12.13 lbs
