Specifications
Certifications
Safety Agency
CE Compliant
Audio
Nominal Diameter
15 inch / 381 mm
Rated Impedance
8 ohm
Minimum Impedance
6.8 ohm
Program Power
1300 W
Power Handling Capacity
650 W
Sensitivity
100.0 dB
Frequency Range
40 - 3000 Hz
Construction
Voice Coil Diameter
3.5 inch / 89 mm
Voice Coil Winding Material
Copper
Voice Coil Length
17 mm / 0.67 inch
Number Of Layers
2
Kind Of Layers
Inside/Outside
Top Plate Thickness
11 mm / 0.43 inch
Cone Design
Curved
Surround Material
Polycotton
Surround Design
M-roll
Magnets
Neodymium
Dual-Force Air Ventilation
Yes
Spider
03
Effective Piston Diameter
330 mm / 12.99 inch
Max. Excursion Before Damage
39 mm / 1.54 inch
Thiele-Small Parameters
Resonance Frequency (Fs)
42 Hz
DC Resistance (Re)
5.60 ohm
Mechanical Factor
4.00 Qms
Electrical Factor
0.24 Qes
Total Factor
0.22 Qts
Bl Factor
22.50 T x m
Effective Moving Mass (Mms)
80.0 g
Equivalent Vas Air Loaded
191.0 liters
Effective Piston Area (Sd)
0.090 m2
Max. Linear Excursion (Xmax)
6 mm
Voice Coil Inductance @ 1kHz (Le1k)
1.65 mH
Half-Space Efficiency (Eff)
5.68%
Dimensions
Overall Diameter
393 mm / 15.47 inches
Height
180 mm / 7.09 inches
Bolt Circle Diameter
371-376 mm / 14.61-14.8 inch
Bolt Hole Diameter
7 mm / 0.28 inch
Front Mount Baffle Cut-Out
354 mm / 13.94 inch
Rear Mount Baffle Cut-Out
354 mm / 13.94 inch
Volume Occupied By Driver
3.8 liters / 0.15 ft3
Weight
Product Weight
5.16 kg / 11.38 lbs
Shipping
Package Height
230 mm / 9.06 inches
Package Width
440 mm / 17.32 inches
Package Depth
440 mm / 17.32 inches
Package Weight
6.52 kg / 14.37 lbs
