Specifications
Certifications
Safety Agency
CE Compliant
Performance
Nominal Diameter
15 inch / 381 mm
Rated Impedance
8 ohm
Minimum Impedance
6.5 ohm
Program Power
1400 W
Power Handling Capacity
700 W
Sensitivity
99.0 dB
Frequency Range
40 - 2500 Hz
Effective Piston Diameter
330 mm / 12.99 inch
Max. Excursion Before Damage
40 mm / 1.57 inch
Dual-Force Air Ventilation
Yes
Construction
Voice Coil Diameter
3.5 inch / 89 mm
Voice Coil Winding Material
Copper
Voice Coil Length
19 mm / 0.75 inch
Number Of Layers
2
Kind Of Layers
Inside/Outside
Top Plate Thickness
10 mm / 0.39 inch
Cone Design
Curved
Surround Material
Polycotton
Surround Design
M-roll
Magnets
Ceramic
Spider
03
Thiele-Small Parameters
Resonance Frequency (Fs)
46 Hz
DC Resistance (Re)
5.40 ohm
Mechanical Factor (Qms)
6.70
Electrical Factor (Qes)
0.33
Total Factor (Qts)
0.31
Bl Factor (Bl)
22.80 T x m
Effective Moving Mass (Mms)
106.0 g
Equivalent Air Load (Vas)
114.0 liters
Effective Piston Area (Sd)
0.090 m2
Max. Linear Excursion (Xmax)
7 mm
Voice Coil Inductance @ 1kHz (Le1k)
0.90 mH
Half-Space Efficiency (Eff)
3.20%
Dimensions
Height
167 mm / 6.57 inches
Diameter
393 mm / 15.47 inches
Overall Diameter
393 mm / 15.47 inches
Bolt Circle Diameter
371-376 mm / 14.61-14.8 inch
Bolt Hole Diameter
7 mm / 0.28 inch
Front Mount Baffle Cut-Out
354 mm / 13.94 inch
Rear Mount Baffle Cut-Out
354 mm / 13.94 inch
Volume Occupied By Driver
4.5 liters / 0.18 ft3
Weight
Product Weight
8.2 kg / 18.08 lbs
Shipping
Package Height
209 mm / 8.23 inches
Package Width
439 mm / 17.28 inches
Package Depth
434 mm / 17.09 inches
Package Weight
9.5 kg / 20.94 lbs
