- Acoustical
- Frequency Response (-10dB): 75 Hz ÷ 20000 Hz
- Max SPL @ 1m: 134 dB
- Horizontal coverage angle: 60°
- Vertical coverage angle: 60°
- Directivity index Q: 13
- System Sensitivity: 100 dB
- Power
- Nominal Impedance: 8 ohm
- Power Handling: 600 W
- Peak Power Handling: 2400 W PEAK
- Recommended Amplifier: 1200 W
- Protections: Dynamic active mosfet
- Crossover Frequencies: 1100 Hz
- Transducers
- Compression Driver: Coaxial 1.3'' neo, 2.5'' v.c
- Woofer: Coaxial 15'' neo, 3.0'' v.c
- Input/OutputInput connectors: Neoprene Cable
- Standard Compliance
- IP protection grade: IP 55
- CE marking: Yes
- Physical
- Cabinet/Case Material: PE Low Density
- Hardware: 12 x M10 + U-Bracket and Pair of spacers
- Grille: Aluminum with waterproof clothing
- Color: Gray, White - RAL 9003
- Dimensions (HxWxD): 18.23x18.23x17.05" (463x463x433 mm)
- Weight: 17 kg / 37.48 lbs
- Shipping Dimensions (HxWxD): 20.43x19.25x19.25" (519x489x489 mm)
- Package Weight: 47.18 lbs (21.4 kg)
