RCF RC 401 US Wall Mount Remote Control For DMA Series | White

RCF RC 401 US Wall Mount Remote Control For DMA Series | White

SoundPro Item: 47278 | Part Number: RC-401W

$169.00
$199.00 $169.00
Your Price Sold out
MSRP: $199.00 | MAP: $169.00

Usually ships in 5-7 business days

  • Compatible With RCF DMA 82 And DMA 162 Digital Mixer Amplifiers
  • Master Volume Adjustment Gives Zone Operators Direct Level Control
  • Output Mute Function Silences All Outputs From The Wall Plate
  • Input Program Selection Lets Users Switch Sources Without Head Unit Access
  • CAT5 Shielded Cable Connection Simplifies Structured Wiring Installs
  • No External Power Supply Required, Draws Power From The DMA Unit
  • Available In Black Or White To Match Installed Wall Plate Aesthetics
Log in or register for YOUR best price

The RCF RC 401 US is a wall mount remote control panel designed for AV integrators deploying RCF DMA 82 or DMA 162 digital mixer amplifiers in installed sound environments. It gives operators at any zone location direct control over master output volume, output mute, and input program selection, eliminating the need to access the head unit during events or daily operation. One controller connects per DMA power output, allowing multi-zone installations to be scaled logically without complex wiring infrastructure.

Connection is made via CAT5 shielded cable using screw terminals, aligning with standard US installation practices and keeping wall-plate integration straightforward for installers familiar with commercial AV structured wiring. The controller requires no external power supply, drawing what it needs from the DMA unit itself. This simplifies conduit planning and reduces material cost in retrofit and new-construction installs alike.

For integrators specifying distributed audio systems in houses of worship, corporate AV, hospitality, or education environments, the RC 401 US offers a compact, purpose-built control point where a full control surface is unnecessary. Available in two finish options to match wall plate aesthetics, it is CE compliant and built in a plastic enclosure sized to fit standard US gang box cutouts.

View full details

Specifications

Certifications
Safety Compliance
CE compliant
General
Functions
Master volume, mute, select input
Installation Standard
Compatible with US installation standard
Compatible Units
DMA 82 and DMA 162
Connectable Items
One per DMA power output
Connectors
Screw terminals
Power Supply
Not required
Construction
Cabinet Material
Plastic
Color
White - RAL 9003
Dimensions
Height
105 mm / 4.13"
Width
37 mm / 1.46"
Depth
31 mm / 1.22"
Recessed Depth
16 mm / 0.63"
Weight
Unit Weight
0.22 kg / 0.49 lbs
Shipping
Package Height
88 mm / 3.46"
Package Width
219 mm / 8.62"
Package Depth
156 mm / 6.14"
Package Weight
0.27 kg / 0.6 lbs
