RCF XPS 16K Four-Channel Class D Power Amplifier With DSP

RCF XPS 16K Four-Channel Class D Power Amplifier With DSP

SoundPro Item: 138233 | Part Number: XPS 16K

$17,999.00
$17,999.00 $17,999.00
Your Price Sold out
MSRP: $17,999.00 | MAP: $17,999.00

Usually ships in 5-7 business days

  • 16,000W Total Continuous Output Across Four Independent Channels
  • Dual SHARC And Dual ADAU DSP Engines For Deep Onboard Processing
  • FiRPHASE Linear-Phase Filtering Preserves Transient Accuracy
  • Per-Channel Delay Up To 4000ms Enables Precise System Alignment
  • RDNet Onboard For Full Remote Monitoring And Network Control
  • Programmable GPI And GPO Ports Support Third-Party Automation
  • Onboard Speaker Preset Library Accelerates Venue Setup
Log in or register for YOUR best price

The RCF XPS 16K is built for systems engineers and integrators who need extreme power density without sacrificing processing depth. Delivering 4x4000W continuous at 2.7 ohms from a 2U chassis, it serves high-demand applications including large-format touring rigs, fixed installation arrays, and complex multi-zone systems where rack space is at a premium. Its dual SHARC and dual ADAU DSP architecture provides 40-bit floating-point and 32-bit fixed-point processing simultaneously at 96 kHz, enabling precision alignment and speaker optimization at a level typically reserved for external processor units.

For touring engineers, the onboard speaker preset library and rider-friendly touch interface reduce setup time at each venue, while full RDNet integration allows remote monitoring and control from front-of-house or a system management laptop. For installed sound applications, programmable GPI and GPO ports support automation triggers and third-party control integration. The analog and AES/EBU digital input options on XLR connectors provide flexible signal routing to fit nearly any source infrastructure.

Where competing amplifiers in this power class require supplemental outboard processing, the XPS 16K consolidates FiRPHASE linear-phase filtering, Bass Shaper, dynamic PEQ, multi-band compression, and per-channel delay up to 4000ms directly onboard. The result is a system-ready amplifier that reduces rack depth and cable count without compromising the tuning capabilities that demanding touring and install specs require.

View full details

Specifications

Audio
Amplifier Class
D
Output Power (4 x all channels driven, 2.7 ohm)
4 x 4000 W
Output Power (4 x all channels driven, 4 ohm)
4 x 2600 W
Output Power (4 x all channels driven, 8 ohm)
4 x 1400 W
Frequency Response (-3dB)
20 Hz - 23000 Hz
SNR Analog Inputs (unweighted)
>111 dB
SNR Digital Inputs (unweighted)
>115 dB
Crosstalk
<70 dB
Distortion THD+N (20 Hz - 20000 Hz, 1000 W @ 4 ohm)
<0.2%
Gain (linear mode @ 0 dB)
32 dB
Damping Factor (@ 4 ohm, 20 Hz - 1500 Hz)
>95
Max Burst Length (@ 50 Hz, CF = 7 dB, 4 ohm, 1% THD+N)
200 ms
Processing
DSP
2 SHARC, 40-bit floating point, 96 kHz; 2 ADAU, 32-bit fixed point, 96 kHz
EQ Filters
Peaking, HI/LO-shelving, HI/LO-pass (Butterworth, Linkwitz-Riley, Bessel)
Advanced Algorithms
FiRPHASE, Bass Shaper, air compensation, mid-low correction, driver excursion control, dynamic PEQ, multi-band compressor, pilot tone detection, backup recovery, impedance load measurement
Compressors
RMS limiter, dynamic compressor, power limiter, thermal compressor
Delay (per channel)
0-4000 ms
High-Pass Filter
10 Hz - 1000 Hz
Crossover
2500 - 3500 Hz
Tone Controls
Yes
Automatic Gain Control
Yes
Connectivity
Total Inputs
8
Line Inputs
4
Line Connectors
XLR
Digital Inputs
4
Digital Connectors
XLR
Digital Type
AES/EBU
General Purpose Inputs (GPI)
2
Programmable GPI
Yes
Photo-Coupled GPI
2
Signal Outputs
4
Signal Output Connectors
XLR
Power Output Connectors
Speakon
General Purpose Outputs (GPO)
3
Programmable GPO
Yes
Controls
Configuration
Front panel touch screen, PC Software
Display
4.3" Color TFT Touch Interface
Network
Gigabit Ethernet
RCF Speaker Presets
Yes
RDNet
Onboard
Electrical
Operating Voltage
100-240 V~ 50/60 Hz
Nominal Current AC @ 100-120 V
30 A
Nominal Current AC @ 220-240 V
16 A
Standby Power Consumption
20 W
Idle Power Consumption
90 W
Power Consumption (Max)
5800 W
Main Fuse
Internal
Protections
Cooling
Forced
Short Circuit Protection
Yes
Thermal Protection
Yes
DC Protection
Yes
Fuses
Yes
VHF Protection
Yes
Environmental
Operating Temperature (Continuous)
-5°C to +40°C / +23°F to +104°F
Operating Temperature (Reduced Output)
-5°C to +50°C / +23°F to +122°F
Fan Noise Idle
<35 dBA
Fan Noise Max
<64 dBA
Certifications
Safety Agency
CE, UL 62368-1 3rd Ed., CSA C22.2 No. 62368-1:19 3rd Ed.
Construction
Cabinet Material
Metal
Color
Black - RAL 9005
Handles
2 metal handles for rack mount
Dimensions
Rack Mounting
19", 2U
Height
3.49"
Width
18.98"
Depth
18.99"
Weight
Product Weight
33.07 lbs
Shipping
Package Height
5.91"
Package Width
22.83"
Package Depth
23.62"
Package Weight
39.68 lbs
