RCF BD-42EN-12W Bidirectional Sound Projector

RCF BD-42EN-12W Bidirectional Sound Projector

SoundPro Item: 203298 | Part Number: BD-42EN-12W

$159.00
$229.00 $159.00
Your Price Sold out
MSRP: $229.00 | MAP: $159.00

Usually ships in 5-7 business days

  • 2x5" fullrange transducers.
  • Power selectable (100 V): 12 W – 6 W – 3 W – 1,5 W.
  • 91 dB sensitivity.
  • Colour grey RAL 7035.
  • Flameproof ABS body, aluminium grilles and bracket.
  • In/out ceramic terminal block.
  • Thermal fuse protection.
  • Protection grade IP55.
Log in or register for YOUR best price

BD 42EN is a bidirectional sound projector featuring an elegant aesthetic and easy orientation, suitable for the sonorization of commercial and industrial environments where a good sound quality and high intelligibility and efficiency are required. It features a cylindrical plastic body with aluminium grilles and U-bracket support. Thanks to its IP55 protection grade, it can be installed both indoor and outdoor.

View full details

Specifications

ACOUSTICAL SPECIFICATIONS
Frequency Response (-10dB)
130 Hz - 15000 Hz
Max SPL @ 1m
102 dB
Max SPL @ 4m
90 dB
System Sensitivity
90 dB
System Sensitivity 1W @ 4m
78 dB
POWER SECTION
Amplification
Full Range
Power Handling
12 W
Peak Power Handling
48 W PEAK
Protections
Thermal fuse
Recommended Amplifiers
DXT 3000; DXT 4000; DXT 7000
TRANSDUCERS
Fullrange
2 x 5.0''
INPUT/OUTPUT SECTION
Input Connectors
Ceramic screw terminals
Output Connectors
Ceramic screw terminals
Constant Voltage Transformer
100 V
Power Selection 1
12 W - 833 ohm
Power Selection 2
6 W - 1667 ohm
Power Selection 3
3 W - 3333 ohm
Power Selection 4
1.5 W - 6667 ohm
STANDARD COMPLIANCE
IP Protection Grade
IP 55
Safety Agency
CE compliant
EN54-24 Certified
Yes
CPR Number
0068-CPR-234/2025
PHYSICAL SPECIFICATIONS
Cabinet/Case Material
ABS
Hardware
Aluminum U bracket
Grille
Aluminium
Color
Grey; RAL 7035
SIZE & WEIGHT
Width
200 mm; 7.87 inches
Diameter
138 mm; 5.43 inches
Weight
1.66 kg; 3.66 lbs
SHIPPING INFORMATION
Package Height
290 mm; 11.42 inches
Package Width
160 mm; 6.3 inches
Package Depth
190 mm; 7.48 inches
Package Weight
1.95 kg; 4.3 lbs
