RCF XPS 16KD Dante-Equipped 4-Channel DSP Power Amplifier

RCF XPS 16KD Dante-Equipped 4-Channel DSP Power Amplifier

SoundPro Item: 139991 | Part Number: XPS 16KD

Pricing available upon request

Pricing available upon request

Your Price Sold out

Usually ships in 5-7 business days

  • Dante Audio Networking Eliminates Dedicated Snake Infrastructure
  • 40-bit Floating-Point DSP Supports Advanced Signal Processing Up To 96 kHz
  • Comprehensive Channel Processing With Delay, EQ, Crossover, And Compression
  • RDNet Networked Management With Onboard 4.3" Touch Display
  • Class D Efficiency Delivers 16000 W In Compact 2U Chassis
  • FiRPHASE Technology And Bass Shaper For Transparent Sound
  • Four Independent General Purpose Outputs Enable Custom Routing
Log in or register for YOUR best price

The RCF XPS 16KD is purpose-built for touring sound engineers, system integrators, and live production teams who demand network-ready amplification with transparent audio fidelity and extensive onboard processing. Its four independent channels deliver 4000 W per channel at 2.7 ohms, making it suitable for bi-amped or quad-amped speaker configurations without external processing chains.

Dante digital audio networking eliminates dedicated analog snake runs, reducing setup time and cabling complexity in both temporary event installations and permanent venue deployments. The 40-bit floating-point DSP engine handles channel-independent processing—including delay, multiband compression, FIR filtering, and crossover functions—allowing each output to be independently optimized for its connected speaker load. RDNet onboard management and the 4.3-inch color touch interface provide immediate visual feedback and remote control across networked systems.

XPS 16KD excels in mid-to-large format touring rigs and installed systems where compact 2U footprint, thermal efficiency, and rider compatibility are essential. Advanced algorithms such as FiRPHASE, Bass Motion Control, and impedance load measurement ensure system stability and sonic consistency across varying speaker arrays and venue acoustics.

Downloads

View full details

Specifications

Amplifier Output
Amplifier Class
D
Output Power @ 2.7 Ohm
4 x 4000 W
Output Power @ 4 Ohm
4 x 2600 W
Output Power @ 8 Ohm
4 x 1400 W
Frequency Response
20 Hz - 23000 Hz
Audio Performance
SNR Analog Inputs
>111 dB
SNR Digital Inputs
>115 dB
Crosstalk
<70 dB
Distortion (THD+N)
<0.2 %
Gain (Linear Mode)
32 dB
Damping Factor
>95
Max Burst Length
200 ms
Processing
DSP Processors
2 SHARC 40-bit Floating Point, 2 ADAU 32-bit Fixed Point
Sampling Rate
96 kHz
EQ Filters
Peaking, HI/LO-Shelving, HI/LO-Pass (Butterworth, Linkwitz-Riley, Bessel)
Delay Range
0 - 4000 ms per Channel
High-Pass Filter Range
10 Hz - 1000 Hz
Crossover Range
2500 - 3500 Hz
Advanced Algorithms
FiRPHASE, Bass Shaper, Air Compensation, Mid-Low Correction, Driver Excursion Control, Dynamic PEQ, Multi-Band Compressor, Pilot Tone Detection, Impedance Load Measurement
Connectivity
Line Inputs
4 x XLR
Digital Inputs
12 (Ethercon and XLR)
Digital Type
AES/EBU, Dante
General Purpose Inputs
2 Photo-Coupled, Programmable
Signal Outputs
4 x XLR
Power Outputs
4 x Speakon
General Purpose Outputs
3 Programmable
Network
Gigabit Ethernet
Protections
Short Circuit Protection
Yes
Thermal Protection
Yes
DC Protection
Yes
Fuse Protection
Yes
VHF Protection
Yes
Environmental Operating
Temperature Range (Continuous)
−5°C to +40°C
Temperature Range (Reduced Power)
−5°C to +50°C
Fan Noise (Idle)
<35 dBA
Fan Noise (Maximum)
<64 dBA
Cooling
Forced Air
Electrical Power
Operating Voltage
100-240 V~, 50/60 Hz
Nominal Current @ 100-120 V
30 A
Nominal Current @ 220-240 V
16 A
Standby Power Consumption
20 W
Idle Power Consumption
90 W
Maximum Power Consumption
5800 W
Main Fuse
Internal
Fuse Rating
F 315 mA H 100 V
Dimensions
Height
3.49"
Width
18.98"
Depth
18.99"
Weight
Unit Weight
33.07 lbs
Shipping
Package Height
5.91"
Package Width
22.83"
Package Depth
23.62"
Package Weight
39.68 lbs
Physical Specifications
Rack Mounting
19", 2U
Cabinet Material
Metal
Handles
2 Metal Handles
Color
Black - RAL 9005
Certifications
Safety Compliance
CE, UL 62368-1 3rd Ed., CSA C22.2 No. 62368-1:19 3rd Ed.
