Specifications
Dimensions
Diameter
13.07"
Effective Length
9.06"
Dimensions
18.03" x 5.69" x 13.94"
Weight
Record Weight
recommended 1.76 pounds
Useable Weight of Pick-Ups
3.5~8.5 g (incl. headshell 13~18 g)
Electrical
Power Consumption
13 W
Connectivity
Connections
1x Phono/Line Out (gold-plated), 1x GND earth connection
Construction
Material
die cast aluminum
Shipping
Weight
approx. 3.31 pounds
General
Type
direct-drive turntable
Drive
quartz driven upper-torque direct drive
Motor
16-pole, 3-phase, brushless motor
Turntable Speeds
3 speeds, manual (33 1/3, 45, 78 RPM)
Starting Torque
2.8 – 4.5 kg/cm (adjustable)
Adjustable Stop Time
(0.2 - 6 sec.)
Start-up Time/Change to RPM
<0.2 sec
Wow and Flutter
0.01% WRMS*
S/N Ratio
> 55dB (DIN-B)
Brake System
electronic brake
Overhang
0.59"
Tracking Error Range
< 3°
Offset Angle
22°
Stylus Pressure
0-4 g
VTA Setting Range
0-6mm
Anti-Skating Range
0-3g
Effective Tone Arm Mass
12.8 g (incl. Reloop Headshell ~10 g)
Power Supply
AC 115/230 V, 60/50 Hz (EU/US), AC 100 V, 50/60 Hz (JP)
