Specifications
Operating Frequency
470 – 928 MHz
Bandwidth
458 MHz
Average return loss
10 dB
Impedance
50Ω
Pattern type
Hypercardiod
Polarization
RHCP
Beam width
120°
Gain @ 500 MHz
3 dBi
Dimensions
10” x 12” x 1”
Weight
.9 kg / 2 lbs
Mounting Interface
5/8”-27, 3/8”-16
Operating temperature
-10-40° C / 14-104° F
IP rating
IP44
Color
Matte black
Connector
BNC-F
