- Electrical
- Operating frequency: 470–616 MHz*
- Bandwidth: 146 MHz
- Average return loss (Vertical): -10.5 dB
- Average return loss (Horizontal): -8.3 dB
- Impedance: 50Ω
- Vertical Monopole
- Beam width: 360° azimuth
- F/B ratio: 0 dB
- F/S ratio: 0 dB
- Gain: +2 dBd @ 500MHz
- Horizontal Folded Loop
- Beam width: 360° azimuth
- F/B ratio: 0 dB
- F/S ratio: -1 dB
- Gain: -2 dBd @ 500MHz
- Physical
- Length: 105mm / 4.2”
- Height; 204mm / 8”
- Weight: 187g / .5lb
- Mount threads: 1/4-20, 3/8-16, 5/8-27
- Operating temperatur: -23–54°C / -9–130°F
- Color: Black and Gold
- Connector(s): (2) BNC female
