Specifications
Dimensions
Diameter
19mm
Weight
Net Weight
163g
Audio
Polar Pattern
Supercardioid
Output Impedance
25Ω
Sensitivity
-30dB ±2dB re 1V/Pa @ 1kHz
Connectivity
Maximum Output
+8.2dBu (@ 1% THD into 1kΩ)
Output Connection
3 pin XLR, balanced output between Pin 2 (+), Pin 3 (-) and Pin 1 (ground)
Identifiers
Length
255mm
General
Acoustic Principle
Line Gradient
Maximum SPL
130dB (@ 1kHz, 1% THD into 1kΩ load)
Equivalent Noise
13dBA SPL (A - weighted per IEC651)
Dynamic Range
117dB (per IEC651)
Signal/Noise
81dB SPL (A - weighted per IEC651)
Power Req.
48V Phantom Power (44-52V min 5mA)
RF
Frequency Range
40 Hz - 20 kHz
