Specifications
Audio
Frequency Response
0 dBu, Unity Gain, 96kHz, 30 Hz to 45 kHz +/- 0.2 dB, 10 Hz -3 dB
Input Impedance
5.5KΩ
Signal to Noise Ratio
84.4 dB
Connectivity
Max. Input Level
+25.5 dBu
Construction
Gain
0 to 60dB (in 1 dB steps)
General
Noise
-91 dBFS (150Ω Balanced Source, AES Output, 22 Hz to 22kHz, un-weighted, +60 dB Gain)
High Pass Filter
-3 dB @ 80 Hz, 12 dB/Octave Slope
Pad
-10 dB
Dynamic Range
110 dB
Power Cord Type
IEC Standard 3 Pin 18AWG Latching Type
RF
Unity Gain
-110 dBFS
