Specifications
Dimensions
Dimensions (LxWxH)
120x40x40mm
Electrical
Power Requirements
9V alkaline or lithium battery
Audio
Frequency Response
20Hz to 20kHz, +/-0.5dB
THD
less than 0.01%@1kHz, -30dBu input
SNR
80dB @1kHz, -30dBu input
Output
USB Type-C connector output cable
Phantom Power
48V power supplies
Construction
Gain
+20dB to -∞
Shipping
Weight
130g (excluding battery)
General
Input2
1 x XLR mic input, 1 x 1/4″ (6.35mm) guitar input, 1 x 1/8″ (3.5mm) input
Phone Out
1 x 1/8″ (3.5mm) headphone jack
Inputs
Input1
1x XLR mic input, 1 x 1/4″ (6.35mm) guitar input, 1 x 1/8″ (3.5mm) input
