Specifications
Dimensions
Diameter
0.86"
Electrical
Power Requirements
48V phantom power or built-in lithium battery
Audio
Polar Pattern
Cardioid
Output Impedance
150ohm
Sensitivity
-38 +/-3dB (0dB-1V/Pa, at 1kHz 1.5V 2.2K)
Max SPL
f=1kHz, THD<1% 105dB
Signal to Noise Ratio
80dB SPL (per IEC651)
Performance
High Frequency Boost
+6dB
Connectivity
Output Connection
3-pin XLR, balanced output between pin 2(+), pin 3(-) and Pin 1 (Ground)
Shipping
Weight
8.48 oz (240.5 g)
Identifiers
Length
11.1"
General
Transducer Type
Condenser
Dynamic Range
125dB (per IEC651)
High-pass Filter
150Hz
Pad
-10dB
RF
Frequency Range
75 Hz - 20 kHz
Power
Battery Life
150 hours
