Specifications
Components
Capsule Type
Hand-crafted 2/3" True Condenser
Diaphragm Size
17.2 mm gold / mylar
Electrical
Impedance
200 Ohms
Power Supply
48V Phantom Power (P48 according to IEC 61938)
Connector
3-pin male XLR
Audio
Polar Pattern
Cardioid (Omnidirectional capsule available separately)
Frequency Response
20 Hz - 20 kHz
Sensitivity (Cardioid)
6 mV / Pa (-44.5 dBV)
Sensitivity (Figure-8)
2.5 mV / Pa (-52 dBV)
Max SPL
131 dB (0.5% THD @ 1kHz)
Equivalent Noise Level (Cardioid)
18 dB
Equivalent Noise Level (Omnidirectional)
15 dB
Signal-to-Noise Ratio
76 dB
Dimensions
Microphone Length
200 mm (7.87")
Included Items
Microphone
RN17
Shockmount
Custom design
Storage
Wooden box
Transport
Metal case
Adapter
Thread adapter
Documentation
User manual
