- Dimensions 76x62x20mm (with BA 61 battery pack)
- Audio codec
- SePAC (Sennheiser Performance Audio Codec)
- SeDAC (Sennheiser Digital Audio Codec)
- Modulation scheme Digital modulation Link Density Mode
- Weight Approx. 147g (with BA 61 battery pack and belt clip)
- Audio input 3-pin audio socket
- Power consumption Max. 960 mW
- RF output power 25 mW rms, 50 mW peak
- Switching bandwidth 88 MHz
- Operating time 6.5 h (with BA 61 battery pack)
- Modulation Digital modulation long range mode
- Gain
- Mic: adjustable in 3 dB steps from 0 dB to +42 dB
- Line: adjustable in 3 dB steps from -6 dB to +42 dB
- Frequency range
- 470 to 718 MHz, subdivided into 3 ranges:
- SK 6000 A1 - A4: 470 - 558 MHz
- SK 6000 A5 - A8: 550 - 638 MHz
- SK 6000 B1 - B4: 630 - 718 MHz
- 470 to 718 MHz, subdivided into 3 ranges:
- Input impedance
- Mic: 22kΩ
- Line: 1 MΩ
- AF frequency response
- Line: 30 Hz - 20 kHz (3 dB)
- Mic: 30 Hz - 20 kHz (3 dB)
- Frequency stability < 5 ppm
- Tunability 25 kHz steps
- Lower cut-off-frequency
- Mic: adjustable, 30 Hz, 60 Hz, 80 Hz, 100 Hz, 120 Hz
- Line: 30 Hz, 60 Hz, 80 Hz, 100 Hz, 120 Hz
- Instrument cable emulation Adjustable cable length with 3 steps
- Encryption AES 256 and Digital 9000 encryption
