Specifications
Display
Panel Technology
ADS
Display Technology
LCD w/ LED backlight
Viewable Image Size
55"
Aspect Ratio
16:9
Screen Resolution
3840 x 2160
Pixel Pitch
0.32 mm
Pixels Per Inch
81 PPI
Backlight Type
LED Direct-lit
Brightness
350 cd/m2
Contrast Ratio
1200:1
Viewing Angle
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Response Time (Gray to Gray)
8ms
Refresh Rate
60Hz
Active Screen Area
47.62 x 26.79 in / 1209.6 x 680.4 mm
Orientation
Landscape/Portrait
Displayable Colors
1.07 billion
Audio
Audio Input
Stereo Mini Jack x1, HDMI Audio x2, USB-C Audio x1
Audio Output
Stereo Mini-Jack 3.5mm
Connectivity
Digital Input
HDMI 2.0 x 2 with HDCP 2.2, USB-C x1
External Control
RS-232C, LAN (100Mb), IR Remote
Data
USB 2.0 (Media Player), USB-C (Power)
Synchronization
Horizontal (Digital)
15.0 - 136.0kHz
Vertical (Digital)
24.0Hz - 75.0Hz
Electrical
Power Requirements
100-240V AC, 50/60 Hz
Input Current
1.6A @ 100V / 0.6A @ 240V
Power Consumption (On)
100W
Power Consumption (Max)
140W
Power Consumption (ECO Mode Standby)
0.5W
Power Consumption (Network Standby)
2W
Dimensions
Dimensions Without Stand (W x H x D)
49.58 x 27.83 x 2.32 in / 1234 x 707 x 58.9 mm
Shipping Dimensions (W x H x D)
54.57 x 33.27 x 5.12 in / 1386 x 845 x 130 mm
VESA Hole Configuration
400 x 200 mm (M6)
Weight
Net Weight Without Stand
26.46 lbs / 12 kg
Shipping Weight
37.48 lbs / 17 kg
Environmental
Operating Temperature
32-104°F / 0-40°C
Operating Humidity
20% to 80%
Operating Altitude
16,404 ft / 5,000 m
Storage Temperature
-4 - 140°F / -20 - 60°C
Storage Humidity
10-80%
Storage Altitude
16,404 ft / 5,000 m
Certifications
Energy Efficiency Certification
ENERGY STAR 8.0
Included Items
Ships With
Batteries, Power Cord, Wireless Remote Control
Warranty
Limited Warranty
3 years
