Specifications
Display
Panel Technology
ADS
Display Technology
LCD w/ LED backlight
Viewable Image Size
86"
Aspect Ratio
16:9
Screen Resolution
3840 x 2160
Supported Resolutions
HDMI: Up to 3840 x 2160 (60Hz), HDCP 2.2/1.4, USB-C: Up to 3840 x 2160 (60Hz), HDCP 2.2/1.3
Pixel Pitch
0.49 mm
Pixels Per Inch
51 PPI
Backlight Type
LED Direct-lit
Brightness
350 cd/m²
Contrast Ratio
1200:1
Viewing Angle
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Response Time
8ms
Refresh Rate
60Hz
Active Screen Area
74.6 x 41.97" / 1895 x 1066 mm
Orientation
Landscape/Portrait
Displayable Colors
1.07 billion
Horizontal Synchronization Range
15.0 - 136.0kHz
Vertical Synchronization Range
24.0Hz - 75.0Hz
Connectivity
HDMI Inputs
2.0 x 2 with HDCP 2.2
USB-C Input
x1
Audio Input
Stereo Mini Jack x1, HDMI Audio x2, USB-C Audio x1
Audio Output
Stereo Mini-Jack 3.5mm
External Control
RS-232C, LAN (100Mb), IR Remote
Data
USB 2.0 (Media Player), USB-C (Power)
Power
Power Consumption (On)
245W
Power Consumption (ECO Mode Standby)
0.5W
Power Consumption (Network Standby)
2W
Power Consumption (Maximum)
320W
Input Current
3.6A @ 100V / 1.4A @ 240V
Power Requirements
100-240V AC, 50/60 Hz
Dimensions
Dimensions (without stand)
75.87 x 43.26 x 2.36" / 1927 x 1098.6 x 60.0mm
Net Weight (without stand)
71.65 lbs / 32.5kg
VESA Hole Configuration
600 x 400mm (M8)
Environmental
Operating Temperature
32-104°F / 0-40°C
Operating Humidity
20% to 80%
Operating Altitude
16,404' / 5,000m
Storage Temperature
-4 - 140°F / -20 – 60°C
Storage Humidity
10-80%
Storage Altitude
16,404' / 5,000m
Shipping
Shipping Dimensions
81.89 x 49.21 x 8.86" / 2080 x 1250 x 225mm
Shipping Weight
97.00 lbs / 44 kg
Certifications
Operation Hours
16 Hours/ 7 Days
Limited Warranty
3 years
